VERACITY VHW-HWPO HIGHWIRE POE, IP cameras on Coax, Ethernet and PoE over Coax Video Cable

Images are for illustration purpose and may not show the actual product.

Click to Enlarge

Additional Images:

Additional Image for VERACITY VHW-HWPO HIGHWIRE POE, IP cameras on Coax, Ethernet and PoE over Coax Video Cable: VHW-HWPO

Additional Image for VERACITY VHW-HWPO HIGHWIRE POE, IP cameras on Coax, Ethernet and PoE over Coax Video Cable: Diagram

Model: VHW-HWPO
Item #: 808
Manufacturer: Veracity

MSRP: ~~$320.00~~
Our Price:

$249.00

(You save: $71.00)

Two HIGHWIRE devices are required per link
(For example, 1x VHW-HWPO and 1x VHW-HW)

Coax to Ethernet with universal POE

HIGHWIRE POE turns existing video infrastructure into a fast network connection, and converts legacy 12V or 24V power into a universal Power over Ethernet (POE) supply for IP cameras and mega-pixel cameras. This saves the time and cost of replacing old analog cabling, with no need to install extra power for the new camera. Instant operation with no configuration required makes installation of HIGHWIRE POE simple and fast.

Long connection range

Veracity's HIGHWIRE technology can provide a full-duplex 100BASE-T network connection, with no bandwidth restrictions, over up to 500 metres (1650 feet) of RG-11 cable, or 280 metres (930 feet) of CCTV-grade RG-59 cable.

Simply connect the HIGHWIRE POE by the IP camera, and a regular HIGHWIRE at the other end of the cable, and the connection will be established automatically with no configuration required.

Transparent to the network

The HIGHWIRE connection is invisible to Ethernet data and requires no MAC or IP address; to the camera the link looks like any other network cable.

Speed, duplex and crossover are sensed on connection; no setting up is necessary.

Universal power

HIGHWIRE POE can be powered by legacy 12 Volt DC or 24 Volt AC supplies. Connection is via a detachable screw terminal and the type and polarity of the supply are detected automatically.

An optional power supply is available for installations with no legacy power.

HIGHWIRE POE automatically detects and enables power to IP cameras using the universal IEEE 802.3af standard. Up to 6.5 watts of power is available to Power Class 1 or 2 devices.

Practical installation

With absolutely no setting-up or configuration required, installation is simple, and HIGHWIRE POE's compact dimensions allow it to be mounted inside a camera housing.

Optional wall-mounting brackets and a rack-mounting kit are available to suit the needs of each installation.

Range:

Auto-optimizing for all 75 Ohm coaxial cable:

280m (920ft) full-rate over video-grade RG-59 (Up to 350m depending on quality)

350m (1150ft) full-rate over RG-6

500m (1640ft) full-rate over RG-11

Network:

Auto-configuring for speed (10BASE-T or 100BASE-T) and duplex

Use with Cat 5, Cat 5e or Cat 6 patch or crossover cables

POE out:

IEEE 802.3af compliant PSE

Max power out 7W, isolated

Max device power 6.49W

(Power class 1 or 2 devices only)

Power in:

Auto type and polarity detection with detachable screw terminal connector

10-40V DC (max current 800mA at 12V)

20-28V AC (max current 400mA at 24V)

Dimensions:

84 x 54 x 24mm (3.3 x 2.1 x 0.95in) / 102mm (4in) including connector

70g (2.5oz)

Long range networking

VHW-HWPO	HIGHWIRE Ethernet over coax converter with POE out
VHW-HW	HIGHWIRE Ethernet over coax converter
VPSU-12V-U	Universal (UK/US/EU) 12VDC supply for HIGHWIRE/HIGHWIRE POE
VHW-WMB	Wall-mounting bracket for 1x HIGHWIRE POE
VHW-1U	1U Rack-mounting bracket for up to 8x HIGHWIRE
VHW-RMPSU	Power supply for up to 8x HIGHWIRE, complements VHW-1U
