New Video Configuration optimized 16:9 widescreen |
| High reliability DVST ULTIMA-96H series maintain higher product reliability with Embedded hardware and software design. |
| Simple usage It allows users to use it easily with control buttons that are similar ones on VCR. |
| Pentaplex System Pentaplex System provides no recording interruption even while performing following tasks: live, backup, remote view over networking and playback. |
| Flexible recording config Users can assign each camera with different frame rate, resolution and video quality options in order to fit the requirements. |
| Remote monitoring Searching the video history or monitoring recorded images remotely over the Internet with the client program can't be any easier than ever. |
| Backup Use any external USB storage device to backup video clip of your selection easily between time to time and channel to channel. |
| Audio recording You can record up to 16ch sound inputs simultaneously. Moreover, you can listen to the sound in search and live monitoring and play mode. |
| Various recording methods Ultima-96H series provide convenient use with manual recording, recording by dates and days, hourly schedule recording, sensor and motion detection event recording and others to enable unmanned monitoring. |
| P/T/Z control Built-in RS485 port is available to transmit control signal to single or multiple P/T/Z cameras |
| Dual CODEC for video transmission Ultima-96H series can transmit up to 150 fps (based on 960H resolution). |
| Web browser support You can monitor, playback video, or even control PTZ cameras on Internet Explorer web browser. |
| Built in S.M.A.R.T. DVR check HDD's health automatically and send a warning before HDD failures. |
| Language pack Ulitma-96H displays information in language of your choice among the many language sets. |
| Mirroring by internal HDD and e-SATA If you install more than two HDDs, you can use the second HDD for backup for maximum fault tolerance. Also it supports e-SATA for mirroring or mass storage device, such as NAS. |
| Integrated Text Inserter function Ultima-96H records and diplays POS/ATM transactions on screen. |
| Spot monitoring Spot out can be enable to monitor sequentially in other place. |
| Camera input | 32 BNC | |
| Output | 1 HDMI+1 VGA (1 can be used by HD spot) / 1 Programmable SPOT with OSD | |
| Audio input | 16 RCA | |
| Output | 1 RCA | |
| Sensor Input | 16 (NC, NO selectable) | |
| Sensor output | 14 TTL / 2 relay | |
| OS | Embedded Linux OS | |
| Live Display | Real Time | |
| Resolution (Pixel) | 1280×1024, 1280×720, 1920×1080 | |
| Split screen | 1,4,5,6,8,9,12,16,17,20,25,32 | |
| CODEC | H.264 / JPEG for 3G, Dual CODEC | |
| Resolution (Pixel) | 960H(960H), D1, Half 960H, Half D1, CIF, Mixed | |
| Picture quality | 4 steps (Super, High, Medium, Low) | |
| Recording | NTSC area PAL area |
960fps@960H 800fps@960H |
| Display | 1,4,5,6,8,9,12,16,17,20,25,32 | |
| Search mode | Calendar, Event, POS, Panorama, Thumbnail | |
| Network Interface | Gigabit Ethernet | |
| Speed | 60fps@960H | |
| Application | Windows 2000 / XP / Vista / 7 / 8 (PC Client system & IE) / MAC | |
| Web Browser | Internet Explorer, Safari, Firefox | |
| Smart phone App | Android, iPhone for live and search | |
| Interface | USB 2.0 × 3 | |
| Backup device | External HDD, External CD&DVD-RW, Network, Thumb Drive | |
| HDD | 4 SATA(No capacity limit : 4TB of more), 1 e-SATA(up to 12 bays) | |
| Power Consumption | 84W | |
| Operating Temperature | 5 ~ 40°C(41 ~ 104°F) | |
| Relative Humidity | Maximum 80% non-condensing | |
| Dimension | 430(W) × 420(D) × 88(H) mm | |
