Actual Image Recorded
Digital Zoom on above image 1
Digital Zoom on above image 2
Image Device | 1/3” SONY Progressive CMOS |
Effective Pixels | 2.1 Mega Pixel |
Video Signal |
HD-SDI: 1080p@30fps, 25fps 720p@60fps, 50fps, 30fps, 25fps TV Output: NTSC / PAL Selectable |
Lens | 12x Optical /10x Digital Zoom (Auto Focus) |
View Angle Approx. | Approx.52.4° (Wide end) to 4.64° (Tele end) |
Min. Illumination | 1.0 Lux |
WDR | On / Off |
3DNR | On / Off |
Privacy Masking | Max. Zone 8 ea |
Electrical | |
Power Supply | AC24V (±10%) Normal, Built-in Power Line Surge |
Power Requirement | AC24VAC, 950 mA (2.5 A with Heater) |
Power Consumption | Max. 25 W (with Heater) |
Alarm Output | 1 Normal Relays 12VDC/500mA Max (Selectable NC/NO) |
Alarm Input | 4 Normal Dry Contact (Selectable NC/NO) |
Control | RS-485 baud rate: 2400~38.4Kbps (default: 2400bps) |
Access Time | 0.75 second maximum preset recall time |
ID (Camera Address) | Physical 99 |
Mechanical | |
Dimension | Bubble(Ø112) Ø166 x 341 x 255 |
Weight | Approx. 3.5 kg (with Wall Mount) |
Pan Angle | 360° Continuous Rotation |
Tilt Range | 0 ~ 180˚ |
Speed | Maximum Preset Speed: 360°/sec |
Flip | Rotate 180˚ at bottom of tilt |
Auto Scan | 8 Auto Scan include vector scan |
Preset Position | 210 Position with camera status |
Tour | 8 Tour (Preset, Pattern, Scan) |
Pattern | 8 Pattern |
OSD | Display camera ID, Title, Mode, Angle on screen (Multi-Language) |
Environment | |
IP Rating | IP66 (Weather Proof) |
Operating Temperature | -10°C~+50°C (with Heater: -40°C~+50°C) |
Storage Temperature | -20°C~+70°C / ~90% |
Humidity | ~ 80% RH |
Heater(Built-in) | On / Off: -5°C~+5°C |
