Actual Image Recorded
Digital Zoom on above image 1
Digital Zoom on above image 2
Image Device | 2.1 Mega Pixel, 1/3” Exmor SONY CMOS | |
Video Output Mode |
HD-SDI : 1080p@30fps, 1080p@25fps, 720p@60fps, 720p@50fps TV Out : NTSC / PAL Selectable |
|
Effective Pixels | 1984(H) x 1105(V) | |
Unit cell size (um) | 2.8(H) x 2.8(V) | |
S/N Ratio | More than 50 dB | |
Min. Illumination | 0 Lux (IR LED On) | |
Video output | HD-SDI / 1.0 Vp-p Composite (75Ω) | |
Lens | f=3.6~16mm(1.3Mpx.) / f=3.5~16mm(3Mpx.) Varifocal Lens | |
Lens Control | DC IRIS | |
Manual Shutter Speed |
1/30(25), 1/60(50), 1/120(100), 1/240, 1/500, 1/1K, 1/2K, 1/4K, 1/8K, 1/16K, 1/30K, 1/60K |
|
Shutter Speed | Auto / Manual Selectable | |
WDR / BLC | OFF / WDR / BLC Selectable | |
AGC | 0~10 dB | |
3DNR | OFF / LOW / MIDDLW / HIGH | |
White Balance | AUTO / AUTOext / PUSH / MANUAL | |
Digital Zoom Ratio | 1x ~ 20x | |
Digital Slow Shutter | Off, x2, x3, x4 | |
Privacy Masking | Zone 24 ea, On / Off | |
Motion Detection | On / Off | |
Day & Night | True Day & Night with ICR Mechanism | |
IR LED | 850nm, 30ea, up to 20m (65 feet) | |
OSD | Built-in | |
Operating Temperature | 14˚F~122˚F (-10˚C~+50˚C) | |
Storage Temperature | -4˚F~140˚F (-20˚C~+70˚C) | |
Humidity | Operating : Less than 80% / Storage : Less than 95% | |
Power Consumption | DC12V | DC12V (±10%) Max. 370 mA |
Dual | DC12V (±10%), Max. 470 mA / AC24V (±10%), Max. 5.6 W | |
Dimension (mm) | Bubble(Ø100), Ø137 x 96 | |
Weight | Approx. 343 g |
