Model No. | LTD2508HE-C | LTD2516HE-C | |
System | Compression Format | H.264 | |
OS | Embedded Linux | ||
Video | Input | 8CH, BNC (1.0Vp-p, 75Ω) | 16CH, BNC (1.0Vp-p, 75Ω) |
Standard Output | 1*VGA: 1280x1024, 800x600, 1024x768; 1*BNC Mainout; 1*Spot | ||
Advanced Output | Compatible with HDMI 1920x1080 | ||
Audio | Input | 4CH | |
Output | 1CH | ||
Bidirectional Talk | YES | ||
Recording | WD1 (960H) | 240(NTSC) / 200(PAL) fps | 480(NTSC) / 400(PAL) fps |
CIF | 240(NTSC) / 200(PAL) fps | 480(NTSC) / 400(PAL) fps | |
Recording Mode | Schedule, Manual, Motion Detection, Sensor | ||
Playback | Max Playback Channel | 8CH | 16CH |
Search Mode | Time, Event, File Management, Image (Snapshot) | ||
Backup | USB Disk | 1 USB2.0 for portable HDD, DVD-RW | |
DVD Burner | Optional | ||
Backup Format | DAT or AVI | ||
Remote Application | Dual Stream | Master stream: 1~25/30fps@4CIF/CIF l Network stream: 1~6/7fps@CIF |
|
Browser | IE (windows XP/2000/Vista/7) , Safari(Mac OS), Chrome,Firefox | ||
Master Stream in Network | YES | ||
CMS | YES | ||
Mobile Phone | SuperCam/pro/HD for iPad/iPad2/iPhone/Blackberry/Android | ||
User Access | 10 users online with professional authority management | ||
Alarm | Alarm Input | 8CH | 16CH |
Alarm Output | 1CH | 1CH | |
Storage | HDD | 2 x SATA, up to 4TB | 2 x SATA, up to 4TB |
e-SATA | - | ||
Max HDD after Deploying DVD | 1 | 1 | |
PTZ | PTZ | 1*RS485 | |
PTZ Protocol | PELCOP, PELCOD, LILIN, MINKING, NEON, STAR, VIDO, DSCP, VISCA, SAMSUNG, RM110, HY | ||
PTZ Control | Pan, Tilt, Zoom, Preset, Cruise, Trace | ||
Network | Ethernet | 10 /100 / 1,000 Mbps Ethernet (RJ-45) | |
Protocol | TCP/IP, DHCP, DDNS, NTP, SMTP | ||
IR Controller | 1 | ||
Others | Power Supply | DC12V | DC12V |
External IR Receiver Interface | Yes | Yes | |
Operating Temperature | 0°C ~50°C | 0°C ~50°C | |
Humidity | 10% ~ 90% Humidity | 10% ~ 90% Humidity | |
Product Weight | NW: 5.2kg GW:6.2kg | NW: 5.7kg GW:6.7kg | |
Product Dimension | 16.9"(L)×15"(W)×2"(H) | 16.9"(L)×15"(W)×2"(H) |
