KEY FEATURES
Video | In | 8 Ch |
Analog & HD-SDI Magic Detect Function | Yes | |
Source | 720p / 1080i / 1080p / Mixed | |
Output | 1 HDMI / 1 VGA / 1 Programmable SPOT | |
Audio | Input | 4 RCA |
Output | 1 RCA | |
Sensor In | 4 (NC, NO selectable) | |
Alarm Out | 1 Relay | |
Operating System | Embedded Linux OS | |
Display | Speed | Realtime |
Screen Res. (Pixel) | 1280×720, 1920×1080 | |
Split Screen | 1 / 4 / 8 | |
Recording | CODEC | H.264 / JPEG for 3G / Dual CODEC |
Resolution (Pixel) | 720p / 1080i / 1080p / Mixed | |
Picture Quality | 4 steps (Super/High/Medium/Low) | |
Speed Total (fps) | 240 fps @ 1080p | |
Playback | Display | 1 / 4 / 8 |
Search Mode | Calendar / Event / POS / Panorama / Thumbnail | |
Speed(multi-ch mode) | 120 fps @ 1080p | |
Network | Network Interface | 1Gbps (Gigabit Ethernet) |
Protocol | TCP/IP / HTTP / DHCP | |
Application | Windows 2000 / XP / Vista / 7 / 8 (PC Client system & IE) / Mac | |
Web Browser | Internet Explorer | |
Backup | Interface | USB 2.0 × 2 |
Backup device | External HDD / CD & DVD-RW / Network / Thumb Drive | |
Storage | Slot | 2 (No capacity limit) |
Others | Controller | IR Remote Control / Mouse |
Pan / Tilt Camera | Control from RS485 Interface | |
Power Source | AC Adapter DC | |
Operating Temp. | 5~40°C (41~104°F) | |
Relative Humidity | Maximum 80% Non-Considering | |
Dimension | 340(W)×250(D)×60(H)mm 13.4"(W)×9.9"(D)×2.4"(H) |
