| System | Compression Format | H.264 | |
| OS | Embedded Linux | ||
| Video | SDI Camera Input | 4CH 1080P | |
| Standard Output | 1*BNC Mainout 1*BNC Spot 1*VGA: 1280x1024, 800x600, 1024x768 | ||
| Advanced Output | HDMI 1920x1080 | ||
| Audio | Input | 4CH | |
| Output | 1CH | ||
| Bidirectional Talk | YES | ||
| Recording | Frame Rate (SDI) | 1080P: 7fps | |
| Recording Mode | Schedule, Manual, Motion, Sensor | ||
| Playback | Max Playback Channel | 4CH | |
| Search Mode | Time, Event, File Management, Image(snapshot) | ||
| Backup | USB Disk | 1 USB 2.0 port | |
| DVD Burner | Optional | ||
| Backup Format | DAT or AVI | ||
| Remote Application | Dual Stream | YES | |
| Browser | IE9, Safari, Chrome, Firefox | ||
| Master Stream in Network | YES | ||
| CMS | YES | ||
| Mobile Phone | SuperCam/pro/HD for iPad/iPad2/iPhone/Blackberry/Android | ||
| User Access | 10 users online with professional authority management | ||
| Alarm | Alarm Input | 4CH | |
| Alarm Output | 1CH | ||
| Storage | HDD | 2 SATA | |
| Max HDD after Deploying DVD | 1 | ||
| PTZ | PTZ | 1*RS485 | |
| PTZ Protocol | PELCOP,PELCOD,LILIN,MINKING,NEON,STAR,VIDO,DSCP,VISCA, SAMSUNG, RM110,HY |
||
| Network | Ethernet | 1,000 Mbps Ethernet (RJ-45) | |
| Protocol | TCP/IP, DHCP, DDNS, NTP, SMTP | ||
| Other | IR Controller | 1 | |
| Power Supply | 100VAC~240VAC | ||
| Operating Temperature | 0°C ~50°C | ||
| Humidity | 10% ~ 90% Humidity | ||
