EYEMAX IT 6025M HAMMER Dome IR Camera 620 TVL 25 IR IP68 Waterproof
Images are for illustration purpose and may not show the actual product.
Model:
IT 6025M
Item #: 58
Manufacturer: Eyemax
MSRP:
$165.00
Our Price:
$89.00
(You save: $76.00)
This Model has been discontinued.
Please follow the link for our recommended replacement: IT 6035V
- HAMMER® series camera : IP-68 Water & Vandal-proof
- Easy Twist and Lock Installation : No drilling thru camera required (Drill hole guide included)
- 3-Axis Construction : By adjusting '3-Axis' control, you get a straight view regardless whether camera is installed on a wall or ceiling
- SMART IR : 23 IR LED + 2 HIGH luminance IR
- 1/3" Sony Super HAD II color CCD sensor
- High Resolution - 620 (H) TV Line in Color
- Minimum Illumination - 0.1 Lux (Color) / 0 Lux with IR on(B/W)
- 4.3mm Fixed Lens Installed
- OSD (On Screen Display) - Easy camera setup
- 2DDNR (2D Digital Noise Reduction) - less noise clear image quality at night
- DC 12V only
 |
High-Res 620 TV Line
The camera is powered by NEXT chipset that is embodied the top grade of the world at 620 TVL resolution be own image signal technology which is to change the frequency of luminance signal adaptively by a monitoring sector. |
 |
2D DNR (2D DIGITAL NOISE REDUCTION)
Improved S/N ratio 50dB and more sharp and noiseless low light image quality provided by built-in noise reduction (2DDNR: 2D Digital Noise Reduction) function. |
| |
OSD CAMERA SETUP
It has have a small program built-in to the camera to help users to setup the camera function without difficulties. No more reading a manual and tipping dip-switches to configure the camera. |
| |
3-AXIS DOME CONSTRUCTION
Accompanying with 3-Axis construction, the Dome camera can be rotated, shifted horizontally or vertically so you can position the camera to get the pictures you need |
| 620 TV Line |
| Sony 1/3 inch Super HAD II CCD |
| 811(H) x 508(V) 410K Pixel |
| 768(H) x 494(V) 380K Pixel |
| 2:1 Interlace |
| Horizontal : 15.734Khz / Vertical : 59.94Hz |
| More than 50 dB (AGC off) |
| CVBS : 1.0Vp-p / 75 ohm |
| 0.1 Lux at F1.2 (Color) / 0 Lux with IR on (B/W) |
| ATW1 / ATW2 / AWC->SET / Manual Adjustable |
| Auto / Manual - 1/60 sec ~ 1/100,000 sec (NTSC) |
| Built-in |
| OFF / BLC / HLC Selectable |
| LOW / MIDDLE / HIGH / OFF Selectable |
| ON / OFF |
| Auto / COLOR / BW / EXT |
| ON / OFF (8 Zone) |
| ON / OFF (Motion Size : 28 × 15 / 4 AREA) |
| ON / OFF |
| Adjustable |
| -10°C~+50°C(14°F ~ 122°F) / 30% ~ 80% RH |
| -20°C~+60°C(-4°F ~ 140°F) / 20% ~ 90% RH |
| 12VDC |
| Hammer® Case (IP68) / 5.0”(D) × 4.0”(H) |
