1/3" progressive scan CMOS
|
|
1280 (H) x 1024 (V)
|
|
1.5 Lux (1/60 sec), 0.2 Lux (1/5 sec), (F/1.8, AGC‐On, slow shutter‐Off) |
|
Automatic (Balanced, Speed Priority, Quality Priority), Manual (1/5 ~ 1/4000 sec) |
|
Automatic, Manual (2800K ~ 8500K)
|
|
Yes
|
|
Yes (electronic)
|
|
Fixed
|
|
3.6 mm
|
|
F/1.8
|
|
M12, Pitch 0.5 mm
|
|
1/3"
|
|
100.2°
|
|
77°
|
|
54°
|
|
No
|
|
No
|
|
Fixed
|
|
H.264, MPEG4 and MJPEG
|
|
Dual Streams from two of H.264, MPEG4 and MJPEG |
| 30 fps at 640 x 512, 15 fps at 1280 x 1024
* The frame rate and the performance may vary depending on the number of connections and data
bitrates (different scenes). |
|
Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker-less 50/60 Hz, Image Orientation, Shutter Speed, Backlight Compensation, D/N sensitivity
|
|
G.711 |
|
No
|
|
No
|
|
1280 x 960, 640 x 480, 320 x 240
|
|
1280 x 1024, 640 x 512, 320 x 256
|
|
640 x 480, 320 x 240
|
|
640 x 512, 320 x 256
|
|
10/100 Ethernet
|
|
HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, RTSP, PSIA, SNMP, QoS (DSCP)
|
|
M12, Pitch 0.5 mm
|
|
-45° ~45°
|
|
0° ~ 90°
|
|
No
|
|
PoE |
|
RJ‐45 Connector |
|
built-in microphone
|
| No
|
| No
|
|
0 °C ~ 50 °C / 32 °F ~ 122 °F
|
|
10% to 90% (no condensation)
|
|
PoE |
|
5.8 W
|
|
ø 106 x 55.6 mm / 4.2 x 2.2 in
|
|
1 m / 3.28 ft
|
|
ø 8 mm / 0.31 in
|
|
ø 28.5 mm / ø 1.12 in
|
|
212 g / 0.47 lb
|
|
CE, FCC, C-Tick, RoHS compliant
|
|
IEEE 802.3af Power over Ethernet
|
|
End-Span and Mid-Span
|
|
Per Port 48V DC, 350mA. Max. 15.4 watts
|
|
Web-based configuration
|
|
Firmware upgrade through Web Browser or Utility
|
|
Camera live view, video recording, change video quality, zoom in/out, bandwidth control, image snapshot, audio, Wide Angle Lens Dewarping, Picture in Picture, Picture and Picture, Privacy Mask, Text Overlay
|
|
Czech / Danish / English / French / German / Hebrew / Hungarian / Italian / Japanese / Polish / Portuguese / Russian / Serbian / Simplified Chinese / Spanish / Traditional Chinese* Bulgarian, Dutch, Greek, Indonesian, Lithuanian, Norwegian, Persian, Romanian, Slovakian, Slovenian, Thai and Turkish are only supported in V1.07 or later.
|
|
GV-NVR, GV-System, GV-Backup Center, GV-Recording Server
|
|
GV-AView for Android Smartphone, GV-Eye HD for iPad, GV-Eye for iPhone and iPod Touch, GV-GView for Windows PDA, GV-MSView for Windows Smartphone, GV-SSView for Symbian Smartphone, 3G-enabled phone
|
|
IE , GV-MultiView
|
|
GV-Control Center, GV-Center V2, GV-VSM
|
|
