Image Device | 1/4” Sony Double Scan Super HAD CCD II |
Effective Pixels | NTSC : 976(H) x 494(V), PAL : 976(H) x 582(V) |
H. Resolution | 700 TVL |
Lens | 30x Optical (f=3.49~104.02) / 10x Digital Zoom / Semi-Focus |
View Angle Approx. | Approx. 69.5˚ (Wide end) to 2.46˚ (Tele end) |
Min. Illumination | 0.2 Lux/F1.65, 0.001 Lux/DSS, 0.1 Lux/ICR @30IRE |
S/N Ratio | More than 50dB |
WDR | On / Off |
DNR | 3 DNR |
Privacy Masking | Max. 15 zones |
Electrical | |
Power Supply | AC24V (±10%) Normal, Built-in Power Line Surge |
Power Requirement | Adaptor AC24VAC, 1A (2.5A with Heater) |
Power Consumption |
AC24VAC, 850mA / 20W (without Heater) AC24VAC, 2A / 45W (with Heater) |
Alarm Output | 1 Normal Relays 5 VDC / 40 mA Max (Selectable NC / NO) |
Alarm Input | 4 Normal Dry Contact (Selectable NC / NO) |
Control | RS-485 baud rate: 2400 ~ 38.4 Kbps (default: 2400 bps) |
Access Time | 0.75 second maximum preset recall time |
ID (Camera Address) | Physical 99 |
Mechanical | |
Weight | About 1.5 Kg |
Dimension | Ф154 x 138(H)mm (Bubble Dome 112Ф) |
Pan Angle | 360˚ Continuous rotation |
Tilt Range | 0 ~ 180˚ |
Speed | Maximum Preset Speed: 360°/sec |
Flip | Rotate 180˚ at bottom of tilt |
Auto Scan | 8 Auto Scan include vector scan |
Preset Position | 210 Position with camera status |
Tour | 8 Tour (Preset, Pattern, Scan) |
Pattern | 8 Pattern |
On Screen Display | Display camera ID, Title, Mode, and Angle on screen (Multi-Language) |
Multi-language OSD | English, Chinese, Russian, Spanish, German, Italian, French, Netherlandish |
Environment | |
Operating Temperature | -10 ~ +50˚C / Heater On: -40˚C ~ +10˚C |
Heater (Built-in) | On/Off: 0 ~ 10˚C |
Operating Humidity | 80% RH |
Storage Temperature | -40˚C ~ 60°C / ~90% |
