| Video | Camera Input (NTSC, PAL) | 16 BNC |
| Output | 1 BNC / 1 VGA / 1 HDMI | |
| Audio | Audio Input | 4 RCA |
| Output | 1 RCA | |
| Sensor in | 1 (NC / NO selectable) | |
| Alarm out | 1 dry contact | |
| Operating System | Embedded Linux OS | |
| Display | Speed | Realtime |
| Resolution (Pixel) | 720×480 (NTSC), 720×576 (PAL) | |
| Split Screen | 1/4/6/8/9/13/16 Programmable Sequence |
|
| Recording | CODEC | Dual H.264 / JPEG for 3G |
| Resolution (Pixel) | D1 / 2CIF / CIF mixed | |
| Picture Quality | 4 steps (Super / High / Medium / Low) | |
| Total Speed NTSC | 480 fps (CIF) | |
| Total Speed PAL | 480 fps (CIF) | |
| Playback | Display | 1 / 4 / 8 / 16 |
| Search mode | Calendar / Event | |
| Speed | Nomal / REW & FF (recorded speed ×2/4/8/16/32/64 ×½/¼, Frame by Frame / Pause | |
| Network | Network Interface | Ethernet / PPPoE |
| Protocol | TCP/IP / HTTP / DHCP | |
| Application | Windows 2000/XP/Vista/7 (PC client system & IE) | |
| Web Browser | Internet Explorer | |
| Backup | Interface | USB 2.0 × 2 |
| Backup device | Ext. DVD/CD-RW/HDD, Network, USB Thumb Drive | |
| HDD | Supports 2 SATA HDDs - No Capacity Limit | |
| Others | Power Consumption | 60W |
| Operating Temperature | 5~40˚C (41~104˚F) | |
| Relative Humidity | Maximum 80% non-condensing | |
| Dimension | 340(W)×250(D)×60(H)mm | |
