Signal System | NTSC |
Scanning System | 2:1 Interlace |
Scanning Frequency(H) | 15.734 KHz |
Scanning Frequency(V) | 59.94 Hz |
Image Sensor | 1/3” High Sensitivity CCD |
Sync. System | Internal |
Total Pixels Number | 811(H) x 508(V) 410K |
Effective Pixels Number | 768(H) x 494(V) 380K |
Horizontal Resolution | 580 TV Lines |
Video Output Level | 1.0 Vp-p (75Ω, Composite) |
S/N Ratio | More than 52dB (AGC off, BW mode) |
Digital Zoom Ratio | 6.13x |
Lens | DC Iris Vari-focal Lens (f=2.8~10.5mm, F1.2) |
Min. Illumination | 0.05 Lux(Color) / 0.0002 Lux(DSS On, B/W) |
Day & Night System | Electronic Sensitivity-up(DSS), ICR(AGC Type) |
3D-DNR | Level (0~63) |
White Balance | ATW / ANTI-ROL / PUSH / Manual |
AGC | Off / Low / Middle / High |
BLC | Off / Low / Middle / High |
Electronic Shutter Speed | 1/60~1/100,000 sec |
Digital Slow Shutter | Off / 2x~128x Field |
Eclipse Function | On/Off (16 Zones) |
OSD Menu | ENG / KOR / RSN / CHN / SPN / FRN |
WDR (Wide Dynamic Range) | Up to 60dB (Low/Middle/High) |
Privacy Zone | On/Off (8 Programmable Zone) |
Motion detection | On/Off (4 Programmable Zone) |
Stabilizer | On/Off |
D-Effect | V-Flip / Mirror / Rotate |
Night Burst | On/Off |
Power Consumption | Max. 2.4W / 200mA |
Power Voltage | 12VDC/24VAC Dual Voltage |
Dimensions | Surface: 100.0(Ø) x124.5(H)mm / Flush: 100.0(Ø) x111.0(H)mm |
Weight (Net) | Approx. 1210g |
