* The item has been discontinued.
Please contact us for our recommended replacement.
By adopting a proprietary SV-IV DSP chip, the camera delivers clear, high quality pictures even in backlight, by increasing exposure in dark areas while decreasing it in bright areas; a corrected image with clear details results.
At daytime, IR light is fitered away in the camera by the IR-cut filter in order to render color images that humans are used to. When light conditions are too dark to render color images, the IR-cut filter is automatically removed to enable the camera to make use of the IR light to produce a high quality black & white video.
External lens control knobs on back of the camera make installation snd setting up the camera easier. The included 2.8~12mm Auto-Iris Lans and adjustable mount gives you the best shot at any angle.
The high performance SV-IV DSP chip dramatically reduces the hain noise in digital image processing, producing clear, sharp images in low lighting environments.
The built-in removable sun shield that will help ensure you a clear picture and protect the camera from the elements.
Use a day & night or monochrome cameras for the IR Corrected lenses. Regular color cameras will not be affected by the IR corrected lens. When using the day/night or monochrome cameras, nearly any outdoor, as well as some indoor applications, will require, or at least benefit from using IR corrected lenses. This is because many natural light sources also contain infrared light, lighting changes with a higher infrared, lower infrared, or without infrared at all. When using ordinary lenses, the result is a blurred, or in a worst case scenario, a completely unfocused picture.
Resolution | 580 TV Lines | |
Sensor | 1/3 inch SONY DS CCD used | |
Total Pixels | 811(H) x 508(V) 410K pixels (NTSC) | |
Effective Pixels | 768(H) x 494(V) 380K pixels (NTSC) | |
Scanning System | 2:1 Interlace | |
Synchronization | Internal / Line Lock | |
Frequency | horizontal: 15.734KHzVertical: 59.94Hz | |
S/N (Y signal) | More than 52 dB (AGC off, Weight ON) | |
Video Output | CBVS: 1.0Vp~p / 75ohm | |
Min. Illumination | 0.3 Lux at F1.2 (Color) / 0.00004 Lux (Sens-up x256) / 0 Lux at IR on | |
White Balance | ATW / AWC / ManualOutdoor (1,800'K ~ 10,500'K) / Indoor (4,500'K ~ 8,500'K) | |
Electronic shutter speed | Auto / Manual(x256 ~ 1/60sec ~1/120,000sec)Sens-up and sens-up limit is selectable / Flickerless | |
Sens-Up | AUTO / FIXED / OFF (selectable limit x2 ~ x256) | |
O.S.D | Built-in | |
Backlight Compensation | WDR, BLC, Off Selectable | |
Gain Control | Low, High, Off Selectable | |
3DDNR(3D Digital Noise Reduction) | OFF / ON (1 ~ 32 Level Selectable) | |
Day & Night | COLOR / Black & White / Auto / EXT | |
SYNC | INT / LL Selectable | |
Motion Detection | ON / OFF (8 Zone, Alarm output) | |
PRIVACY | ON / OFF (8 Zone) | |
DIS(Digital Image Stabilizer) | ON / OFF | |
Digital Zoom | ON (x10) / OFF | |
MIRROR (H-REV) | ON / OFF | |
FLIP (V-REV) | ON / OFF | |
Blemish Compensation | 256 point (Even 128 point, ODD 128 point) | |
Operating Temperature / Humidity | -10°C ~ +50°C / 30% ~ 80% RH | |
Storage Temperatuure / Humidity | -20°C ~ +60°C / 20% ~ 90% RH |
