Signal System | NTSC |
Scanning System | 2:1 Interlace |
Scanning Frequency(H) | 15.734 KHz |
Scanning Frequency(V) | 59.94 Hz |
Image Sensor | 1/3" High Sensitivity CCD |
Sync. System | Internal |
Total Pixels Number | 811(H) x 508(V) 410K |
Effective Pixels Number | 768(H) x 494(V) 380K |
Horizontal Resolution | 600 TV Lines (BW 650TV Lines) |
Video Output Level | 1.0 Vp-p (75Ω, Composite) |
S/N Ratio | More than 50dB (AGC Off) |
Lens | DC Iris Vari-focal Lens (f=2.8~10.5mm) |
Min. Illumination | 0.05 Lux (Color), 0.005 Lux (B/W) |
Day & Night System | ICR(AGC Type) |
Digital Noise Reduction (SDNR) | Low, Middle, High, Off |
White Balance | ATW, Manual, Push |
AGC | On/Off |
SBLC | Off, Low, Middle, High |
Flickerless | On/Off |
Electronic Shutter Speed | 1/60~1/120,000 |
Manual Shutter Speed | 1/60, 1/250, 1/700, 1/1K, 1/1.6K, 1/2.5K, 1/5K, 1/7K, 1/10K, 1/30K, 1/60K, 1/120K |
Mirror Function | Horizontal |
OSD Menu | English, Chinese |
Privacy Zone | On/Off (4 Programmable Zone) |
Motion detection | On/Off (4 Programmable Zone) |
Power Consumption | Max. 3.6W/300mA |
Power Voltage | 24VAC/12VDC Dual Voltage |
Dimensions | Surface : 100.0 x 124.5 mm / Flush : 100.0 x 111.0 mm |
Weight (Net) | Approx. 844g |
