All in one Multi-functions CCTV tester

The 7 inch touch screen IP camera tester is designed for maintenance and installation of IP analog, HD coaxial cameras as well as other
security equipment. The 1920x1200 resolution enables it to display network HD cameras and analog cameras in high resolution. The unit
supports many ONVIF PTZ and analog PTZ control. Additional, it with other functions UTP cable test and cable scan etc. CCTV installers
often need to carry a variety of testing tools to complete their work. If take the all in one camera tester, making working conditions safer
and increasing productivity. 1 year warranty.

APPLICATIONS:
•CCTV camera / system installation and maintenance
•Network cabling project installation and maintenance
•Dome camera, IPk TVI, CVI, AHD, SDI 4K H.265 camera testing
•Video transmission channel testing
•PTZ controller

FEATURES
• 7 inch retina touch screen, 1920*1200 resolution ?5MP TVI, 4MP CVI, 4MP AHD and SDI/EX-SDI test
•H.265/H.264, 4K video display via mainstream ?Dual window test, IP &Analog camera test
• Built in WIFI, create WIFI hotspot ? HDMI input & output, 1080p
• IP discovery , shortcut button, drop-down menu ?DC12V 2A, DC48V PoE power output
•Rapid ONVIF, auto view video, and create test report ?Quick office(excel ,word ,PPT format ) doc.
•RJ45 cable TDR test, cable quality test ?UTP cable tester
•Backlit buttons
• TesterPlay, tester, android version mobile phone and PC display at the same time
• 8gb Card included

SPECIFICATIONS
New -7 inch retina touch screen ,1920*1200 resolution
New- H.264 &H .265 ,4K video display via mainstream
New-5MP TVI test,2560x1944P12.5FPS,4xzoom ,video record and playback ,coaxial PTZ control and call camera OSD menu
4MP AHD test, 2560x1440P15F/25F/30FHD,4xzoom ,video record and playback ,coaxial PTZ control and call camera OSD menu
4MP CVI test,2560x1440P25F/30F, 4xzoom ,video record and playback ,coaxial PTZ control and call camera OSD menu
HD SDI/EX-SDI camera test ,support 1080P 50/60 FPS
IP & CVBS camera test ,PTZ controller
New- Rapid video, just by one key to detect all network cameras and auto display
TesterPlay (screen projection): tester, mobile phone and PC display at the same time (For android version mobile phone)
Rapid ONVIF, auto log in and display image from the camera, activate Hikvision camera, and also can create testing report
New- IP and analog testing at the same time ,converter test from analog to digital with dual test window IP & CVBS
New- In HDMI in mode, It can converter test from analog to digital with dual test window IP & HDMI in or Analog & HDMI in
New- RJ45 cable TDR test, testcable pair status, length, attenuation, reflectivity, impedance, skew etc
Cable tracer, search BNC cable, network cable and telephone cable from the mess cables
Improvement cable tester, UTP cable, telephone cable etc order and connectivity test, can save testing report, if special
number, need to customize
New- Shortcut button, drop-down menu, can select PoE power ,IP setting, WLAN switch, HDMI IN functions etc in any interface
New- Screen lock, password lock and pattern lock are optional
New- HDMI signal in and out , support 1080P
NEW- Backlit buttons.
New- HDMI signal input,720×480p /720×576p /1280×720p /1920×1080p /1024×768p/1280×1024p /1280×900p /1440×900p display
image ,record and snapshot
New- CVBS loop test, the tester send and receive color bar generator signal ,to check BNC cable
New- Traffic monitoring of the tester "LAN port", display network port or WIFI connection real-time upload and download speeds
and other network parameters
New- Customers self update software ,you can install apps with android version ,such as Skype, wechat etc
ONVIF camera test, support 2592*1520, Network PTZ controller (ONVIF)
Built in Wi-Fi ,display image from the wireless camera , create WIFI hotspot
New- 4K video files and MKV/MP4 media files play
PoE DC48V power output, Max power 24W,12V /2A power output/5V 2A power output, as a power bank
New- Quick office, quick office app ( support excel ,word ,ppt format ) doc. editable
IP discovery, it can auto-scan the whole network segment IP, and auto-modify tester’s IP address
PTZ control supports more than 30 protocols such as PELCO-P, PELCO-D, and SAMSUNG
Video level meter, Video PEAK lever, SYNC level, COLOR BURST measurement
Enhanced Color bar generator, PAL/NTSC multi-system color bar video generator
POE voltage measurement, PING test ,IP address scan, port flashing etc
7.4 V /5000mAh Lithium Ion Polymer Battery, after 6-7 hours charging , working time lasts 10 hours
