| Camera | |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Min. Illumination | 0.01Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/10,000 s |
| Lens | 2.8mm，Angle of view：106 ° |
| Lens Mount | ΦM12 |
| Day & Night | IR cut filter with auto switch |
| DNR | 3D DNR |
| Wide Dynamic Range | 120dB |
| Angle Adjustment | Pan: -30°~ 30°, Tilt: 0 ~ 75°, Rotation: 0 ~ 360° |
| Compression Standard | |
| Video Compression | H.264/ MJPEG/ H.264 Zip+ |
| H.264 Type | Main Profile |
| Video Bit Rate | 32Kbps ~ 16Mbps |
| Dual Streams | Support |
| Audio Compression | G.711/G.722.1/G.726/MP2L2 |
| Audio Bit rate | 64Kbps (G.711)/ 16Kbps (G.722.1)/ 16Kbps (G.726)/ 32-128 Kbps (MP2L2) |
| Image | |
| Max. Resolution | 2688 × 1520 |
| Frame Rate | 60Hz: 20fps (2688×1520), 30fps (1920×1080), 30fps (1280×720) 50Hz: 20fps (2688×1520), 25fps (1920×1080), 25fps (1280×720) |
| Image Setting | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| BLC | Support, zone configurable |
| ROI Codec | Support |
| Network | |
| Network Storage | NAS (Support NFS,SMB/CIFS), ANR |
| Alarm Trigger | Motion detection, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
| Protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General | One-key reset, Flash- prevention, duals tream, heartbeat, mirror, password protection,privacy mask, watermark, IP address filtering, Anonymous access |
| Standard | ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| Interface | |
| Communication Interface | 1 RJ 45 10M/100M Ethernet port |
| On-board Storage | Built-in Micro SD/SDHC/SDXC slot, up to 128GB |
| On-board storage | Yes |
| Alarm interface | 1x alarm I/O |
| Audio interface | Built-in microphone and 1x audio output |
| Reset | Yes |
| Wi-Fi | |
| Wireless Standards | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | 20/40M Hz Support |
| Protocols | 802.11b: CCK, QPSK, BPSK, 802 .11g/n: OFDM |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transfer Rates | 11b: 11Mbps, 11g: 54Mbps, 11n: up to 150Mbps |
| Wireless Range | 50 meters *The performance varies based on actual environment. |
| General | |
| Working Temperature /Humidity |
-22 °F ~ 140°F (-30 °C ~ 60 °C) Humidity 95% or less (non-condensing) |
| Power Supply | DC12V ±25%, PoE (802.3af) |
| Power Consumption | Max. 5W |
| IR Range | Approx. 33ft (10 meters ) |
| Material | Top Cover: Plastic; Base: Metal |
| Weather Proof Ratings | IP67 |
| Impact Protection | IEC60068-2-75Eh, 20J; EN50102, up to IK08 |
| Dimensions | 3.9”×3.8”×2.1” (99.3×96.7×52.8 mm) |
| Weight | 1.32 lbs (600g) |
