| Camera |
|
| Image Sensor |
1/3" Progressive Scan CMOS |
| Min. Illumination |
0.01Lux @ (F1.2,AGC ON),0 Lux withIR |
| Shutter Speed |
1/3 s to 1/10,000 s |
| Lens |
2.8mm，Angle of view：106 ° |
| Lens Mount |
M12 |
| Day & Night |
IR cut filter with auto switch |
| DNR |
3D DNR |
| Wide Dynamic Range |
120dB |
| Angle Adjustment |
Pan:0° - 355°, Tilt: 0° - 75°, Rotation: 0-355° |
| Compression Standard |
|
| Video Compression |
H.264 / MJ PEG |
| H.264 Type |
Main Profile |
| Video Bit Rate |
32 Kbps ~ 8 Mbps |
| Dual Streams |
Support |
| Image |
|
| Max. Resolution |
2688×1520 |
| Frame Rate |
"60Hz: 20fps (2688×1520), 30fps (1920×1080), 30fps (1280×720) 50Hz: 20fps (2688×1520), 25fps (1920×1080), 25fps (1280×720)" |
| Image Setting |
"Rotate Mode, Saturation, Brightnes s , Contras t, Sharpnes s adjus table by client software or web brows er" |
| BLC |
Support, zone configurable |
| ROI Codec |
Support |
| Network |
|
| Network Storage |
NAS (Support NFS,SMB/CIFS), ANR |
| Alarm Trigger |
Motion detection, Tampering alarm, Network dis connect, IP addres s conflict, Storage exception |
| Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General |
One- key res et, Flash- prevention, dual s tream, mirror, pas sword protection, privacy mas k, watermark, IP addres s fitering, Anonymous acces s |
| Standard |
ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| Interface |
|
| Communication Interface |
1 RJ 45 10M/100M Ethernet port |
| On-Board Storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128GB |
| Reset |
Yes |
| Wi-Fi |
|
| Wireless Standards |
IEEE802.11b, 802.11g, 802.11n |
| Frequency Range |
20/40MHz Support |
| Channel Bandwidth |
20/40MHz Support |
| Protocols |
802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM |
| Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transfer Rates |
11b: 11Mbps, 11g: 54Mbps, 11n: up to 150Mbps |
| Wireless Range |
50 meters *The performance varies based on actual environment |
| General |
|
| Working Temperature /Humidity |
"- 22 °F ~ 140 °F (- 30 °C ~ 60 °C) Humidity 95% or les s (non- condens ing)" |
| Power Supply |
DC12V ±10%, PoE (802.3af) |
| Power Consumption |
Max. 5W |
| IR Range |
Approx. 100ft (30 meters ) |
| Weather Proof Ratings |
IP67 |
| Impact Protection |
IEC60068-2-75Eh, 20J; EN50102, up to IK10 |
| Dimensions |
Φ4.4"×3.2"(Φ111×82.0mm) |
| Weight |
1.1 lbs (500g) |
