Image Sensor | 1/2.8" Mega Pixel Sensor |
Effective Pixels | 2 Mega Pixels |
Built-in Lens | 2 Mega Pixel Lens |
Signal System | PAL/NTSC |
Horizontal Resolution | PAL:1920×1080P 25F/S NTSC:1920×1080P 30F/S |
Sync. System | Internal Sync. |
Sensor Area | 5.42×3.41mm |
Video Output | 1.0Vp~p75Ω |
S/N Ratio | More than 50dB (AGC OFF) |
White Balance | Auto Tracking White Balance |
Shutter Speed | 1/25~1/50,000Sec. |
Illumination for Infrared Switching | 3 Lux |
Infrared Wavelength | 850nm |
Mimimum Illumination | 0Lux(Infrared Lamps Turn on) |
IR Leds | 2pcs |
IR Radiation Distance | 15~20m |
Working Temperature | −10°C~50°C |
Storage Temperature | −20°C~60°C |
Power Requirement | DC12V, Max Power Comsumption Less Than 5W (When the infrared lamps turn on) |
Weight | 0.45kg |
