| Image Sensor | 1/2.8" 2Mega Pixel Sensor |
| Effective Pixels | 2.0 Mega Pixels |
| Built-in Lens | 3.6mm Mega Pixel Lens |
| Signal System | PAL/NTSC |
| Horizontal Resolution | PAL:1920×1080P 25F/S NTSC:1920×1080P 30F/S |
| Sync. System | Internal Sync. |
| Sensor Area | 5.42×3.41mm |
| Video Output | EX-SDI & CVBS Output, switch on HD-SDI & CVBS Output |
| S/N Ratio | More than 50dB (AGC OFF) |
| OSD Menu | Support |
| White Balance | Auto Tracking White Balance |
| Shutter Speed | 1/25~1/50,000Sec. |
| IR Leds | 24pcs |
| Weather-proof | IP66 |
| Working Temperature | −10°C~50°C |
| Storage Temperature | −20°C~60°C |
| Power Requirement | DC12V, Max Power Comsumption Less Than 3W (When the infrared lamps turn on) |
| Weight | 0.5kg |
