System | |
Compression | Standard H.265 |
OS | Embedded Linux |
Video | |
Network Input | 32 CH IPC input |
Network Access Bandwidth | 256Mbps |
Network Access Format | 5MP / 4MP / 3MP / 1080P / 960P / 720P@25 / 30fps |
Output | HDMI × 1 : 4K × 2K / 1920 × 1080 / 1280 × 1024 VGA × 1 : 1920 × 1080 / 1280 × 1024 |
Audio | |
Network Input | 32 CH IPC audio input |
2-way Audio | RCA × 1 |
Local Output | RCA × 1 |
Record | |
Record Stream | Dual stream recording |
Resolution | 5MP / 4MP / 3MP / 1080P / 960P / 720P |
Mode | Manual, timer, motion, sensor |
Playback | |
Simultaneous Playback | Max 16 CH |
Search | Time slice / time / event / tag search |
Smart Search | Highlighted color to display the camera record in a certain period of time, different colors refers to different record events |
Function | Play, pause, FF, FB, digital zoom, etc. |
Alarm | |
Mode | Manual, sensor, motion, exception |
Input | 16CH local alarm input, Support IPC alarm input |
Output | 4 CH |
Triggering | Record, snap, preset, e-mail, etc. |
Network | |
Interface | RJ45 10 / 100 / 1000 Mbps × 1 |
PoE Port | RJ45 × 16 |
Protocol | TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP |
Web Client | Max 10 users online |
Mobile Device | |
OS | iOS, Andriod |
Storage | |
HDD | SATA × 8, e-SATA × 1, max 6T per HDD |
Backup | |
Local Backup | U disk, USB mobile HDD |
Network Backup | Yes |
Port | |
USB | USB 2.0 × 1 (front panel), USB 3.0 × 1 (rear panel) |
Remote Controller | Included |
Others | |
Power Supply | ATX |
Consumption | ≤ 15W ( without HDD ) |
Dimensions (mm) | 430 × 450 × 90 ( W × D × H ) |
Work Environment | −10 ~ 50 ºC, 10% ~ 90% humidity |
