Model

HCC5321R-IR-Z

Camera

Image Sensor

1/2.7″ 2.1Megapixel CMOS

Effective Pixels

1928(H)×1088(V)

Electronic Shutter

1/3s~1/300,000s

Video Frame Rate

25/30/50/60fps@720P; 25/30fps@1080P

Synchronization

Internal

Min. Illumination

0.03Lux/F1.4, 0Lux IR on

Video Output

1-channel BNC HDCVI high definition video output & CVBS

standard definition video output

Camera Features

Max. IR LEDs Length

200ft, Smart IR

Day/Night

Auto(ICR) / Color / B/W

Backlight Compensation

120dB True WDR

Noise Reduction

2D/3D

OSD Menu

Multi-language

Lens

Focal Length

2.7~12mm

Angle of View

H: 99º~37º

Lens Type

Motorized / Fixed Iris

Mount Type

Φ14

General

Power Supply

DC12V±25%

Power Consumption

Max 10W

Working Environment

-30°C~+60°C / Less than 95%RH (no condensation)

Transmission Distance

Over 500m via 75-3 coaxial cable

Ingress Protection

IP67

Dimensions

Φ122mm×102mm

Weight

0.55kg

Material

Metal
