Model |
SV-HDW7220 |
Camera |
|
Image Sensor |
1/2.8″ 2Megapixel CMOS |
Effective Pixels |
1920(H)×1080(V) |
Electronic Shutter |
1/60s~1/60,000s |
Video Frame Rate |
25/30fps@1080P, 25/30/50/60fps@720P |
Synchronization |
Internal |
Min. Illumination |
0.01Lux@F1.2(AGC ON) |
Video Output |
1-channel BNC HDCVI high definition video output/ CVBS 960H definition video output (Can switch) |
Camera Features |
|
Max. IR LEDs Length |
N/A |
Day/Night |
Auto / Color / B/W |
Noise Reduction |
2D |
OSD Menu |
Support |
Lens |
|
Focal Length |
3.6mm |
General |
|
Power Supply |
DC12V±10% |
Power Consumption |
Max 8W |
Working Environment |
-20°C~+60°C / Less than 95%RH (no condensation) |
Transmission Distance |
Over 500m via 75-3 coaxial cable |
Ingress Protection |
N/A |
Dimensions |
Φ120mm×60mm |
Weight |
0.18kg |
