Camera

Image Sensor

1/2.7″ 2Megapixel CMOS

Effective Pixels

1930(H)×1088(V)

Electronic Shutter

1/60s~1/100,000s

Video Frame Rate

30fps@1080P

Synchronization

Internal

Min. Illumination

0.02Lux/F2.0, 0Lux IR on

Video Output

1-channel BNC HDCVI high definition video output

Camera Features

Max. IR LEDs Length

50m, Smart IR

Day/Night

Auto(ICR) / Color / B/W

Noise Reduction

2D

Lens

Focal length

3.6mm (6mm, 8mm optional)

Angle of View

H: 89.9º(59.4º/41.4º)

Mount Type

M12

General

Power Supply

DC12V±20%

Power Consumption

Max 4.5W

Working Environment

-30°C~+60°C / Less than 95%RH (no condensation)

Transmission Distance

Over 500m via 75-3 coaxial cable

Ingress Protection

IP67

Dimensions(W×D×H)

241.8mm×90.2mm×83.7mm

Weight

0.635kg

Material

Metal
