Camera

Image Sensor

1/2.8″ 2.4Megapixel CMOS

Effective Pixels

1984(H)×1225(V)

Electronic Shutter

1/3s~1/100,000s

Video Frame Rate

25/30/50/60fps@720P; 25/30fps@1080P

Synchronization

Internal

Min. Illumination

0.05Lux@F1.2(AGC ON), 0Lux IR on

Video Output

1-channel BNC HDCVI high definition video output/ CVBS

standard definition video output (Can switch)

Camera Features

Max. IR LEDs Length

20m, Smart IR

Day/Night

Auto(ICR) / Color / B/W

Noise Reduction

2D/3D

OSD Menu

Support

Lens

Focal length

3.6mm

Mount Type

M12

General

Power Supply

DC12V±10%

Power Consumption

Max 4.5W

Working Environment

-30°C~+60°C / Less than 95%RH (no condensation)

Transmission Distance

Over 300m via 75-3 coaxial cable

Ingress Protection

IP66

Dimensions(W×D×H)

Φ65mm×154.7mm

Weight

0.38kg

Others

Default: bracket included
