LENS OPTIONS
Lens |
Fixed Board Lens |
||
Focal Length | 2.97 | 3.6 | 6 |
Aperture | F2.0 | F2.0 | F2.0 |
Image Device | 1/3" 960H SONY EXview HAD CCD ll |
Scanning System | 2:1 Interlace |
Scanning Frequency | NTSC: 15.734 KHz(H), 59.94 Hz(V) / PAL: 15.625 KHz(H), 50 Hz(V) |
H. Resolution | 700 TVL |
Total Pixels | NTSC: 1020(H) x 508(V) / PAL: 1020(H) x 596(V) |
Effective Pixels | NTSC: 976(H) x 494(V) / PAL: 976(H) x 582(V) |
S/N Ratio | More than 50dB (AGC Off) |
Min. Illumination | 0.05 Lux (30IRE@F2.0) |
Sync. System | Internal |
Gamma | r = 0.45 |
Video Output | 1.0 Vp-p Composite (75Ω) |
Lens | Fixed Board Lens Built-in |
Electronic Shutter | NTSC: 1/60~1/100,000 sec / PAL: 1/50~1/100,000 sec (Auto) |
2DNR | AUTO |
Day & Night | COLOR |
IP Rating | IP66 (Weather Proof) |
Operating Temperature | 14˚F ~ 122˚F (-10˚C~ + 50˚C) |
Storage Temperature | -4˚F ~ 140˚F (-20˚C~ + 60˚C) |
Power Consumption | DC12V ±10% Max. 110 mA |
Dimensions (mm) | Bubble (59.5 Φ), 81Φ x 63 |
Weight | Approx. 216 g |
Options | Digital Day & Night |
Optional Colors | Black / White |
