Model

DH-CA-HFW1100SP

DH-CA-HFW1100SN

Camera

Image Sensor

1/2.9″ 1Megapixel CMOS

Effective Pixels

1280(H)×720(V)

Electronic Shutter

1/50s~1/100,000s

1/60s~1/100,000s

Video Frame Rate

25fps@720P

30fps@720P

Synchronization

Internal

Min. Illumination

0.01Lux@F1.2(AGC ON), 0Lux IR on

Video Output

1-channel BNC HDCVI high definition video output

Camera Features

Max. IR LEDs Length

20m, Smart IR

Day/Night

Auto(ICR) / B&W / Color

Noise Reduction

2D

Lens

Focal length

6mm (2.8 mm, 3.6mm, 8mm optional)

Mount Type

M12

General

Power Supply

DC12V±10%

Power Consumption

Max 3.5W

Working Environment

-30°C~+60°C / Less than 95%RH (no condensation)

Transmission Distance

Over 500m via 75-3 coaxial cable

Ingress Protection

IP66

Dimensions(W×D×H)

Φ65mm×154.7mm

Weight

0.38kg

Others

Default: bracket included
