Model

HVR908S-16

System

Main Processor

Embedded Processor

Operating System

Embedded LINUX

Video

Input

16 channel, BNC

Standard

Analog

NTSC/PAL

HDCVI

1080P/720P HDCVI Camera

IP

16+48 up to 12Mp

Audio

Input

16 channel, BNC

Output

1 channel, BNC

Two-way Talk

1 channel BNC(independent)

Display

Interface

HDMI1(4K)，HDMI2( 1080P), 1 VGA,VIDEO OUT

Resolution

3840×2160(HDMI1,)1920×1080, 1280×1024, 1280×720, 1024×768

Display Split

1/4/8/9/16/25/36

Privacy Masking

4 rectangular zones (each camera)

OSD

Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Recording

Video Compression

H.264

Audio Compression

G.711/PCM

Record Rate

Main Stream:

1080P(1~30fps)

/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps)

Extra Stream

960H/D1/CIF/QCIF(1~25/30fps)

Bit Rate

32~8192Kb/s

Record Mode

Manual, Schedule(Regular(Continuous), MD), Stop

Record Interval

1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

Video Detection

Trigger Events

Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips

Video Detection

Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank

Alarm Input

16 channel

Relay Output

6 channel

Intelligent Video

(Optional)

Tripwire, Intrusion, Abandoned/Missing, Face Detection

Playback & Backup

Sync Playback

1/4/9/16

Search Mode

Time/Date, MD & Exact search (accurate to second)

Playback Functions

Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom

Backup Mode

USB Device/Internal SATA burner/Network

Network

Ethernet

2 Gigabit ports

Network Functions

HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P

Max. User Access

128 users

Smart Phone

iPhone, iPad, Android, Windows Phone

Storage

Internal HDD
