Model

HNC5241E–IR-Z

Camera

Image Sensor

1/3”4Megapixel progressive scan CMOS

Effective Pixels

2688(H)x1520(V)

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3(4)~1/10000s

Min. Illumination

0.01Lux/F1.4(Color);0Lux/F1.4(IR on)

S/N Ratio

More than 50dB

Video Output

1 port

Camera Features

Max. IR LEDs Length

50m

Day/Night

Auto(ICR)/Color/B/W

Backlight Compensation

BLC / HLC /WDR(120dB)

White Balance

Auto/Manual

Gain Control

Auto/Manual

Noise Reduction

3D

Privacy Masking

Up to 4 areas

Lens

Focal Length

2.7mm~12mm

Max Aperture

F1.4

Focus Control

Motorized

Angle of View

H: 100°~33°

Lens Type

Motorized/ Auto Iris(DC)

Mount Type

Board-in Type

Video

Compression

H.264/H.264H/H.264B/MJPEG

Resolution

4M(2560×1440)/3M(2304×1296)/1080P(1920×1080)/1.3M(1280×96

0)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×240

)

Frame Rate

Main Stream

4M(1~20fps)/3M(1 ~ 25/30fps)

Sub Stream

D1/CIF(1 ~ 25/30fps)

Third Stream

720P(1~5/8fps)   WDR on

720P(1~18/2fps)   WDR off

Bit Rate

H.264: 32K ~ 10Mbps

Corridor mode

Support

Audio

Compression

G.711a/ G.711u/ AAC

Interface

1/1 channel In/Out

Smart Function

Smart detection

Tripwire

Intrusion

Scene change

Face detect

Network

Ethernet

RJ-45 (10/100Base-T)

Wi-Fi

N/A

Protocol

IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour

ONVIF

ONVIF,PSIA,CGI

Max. User Access

20users

Smart Phone

iPhone, iPad, Android, Windows Phone

Auxiliary Interface

Memory Slot

Micro SD, Max 128GB

RS485

N/A

Alarm

1/1 channel In/Out

PIR Sensor Range

N/A

General

Power Supply

DC12V(AC24V optional),PoE (802.3af)

Power Consumption

Max 10W (with IR on, motorized lens working)

Working Environment

-40°C~+60°C, Less than 95% RH

Ingress Protection

IP67

Vandal Resistance

IK10

Dimensions

Φ159mm×117.9mm

Weight

0.8kg
