Model

HNC5440

Camera

Image Sensor

1/3” 4Megapixel progressive scanCMOS

Effective Pixels

2592(H)x1520(V)

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3(4)~1/10000

Min. Illumination

0.01lux/F2.0(color),0.001Lux@F2.0(B/W)

S/N Ratio

More than 50db

Video Output

N/A

Camera Features

Max. IR LEDs Length

N/A

Day/Night

Auto(Electronic)/Color/B/W

Backlight Compensation

BLC/HLC/DWDR

White Balance

Auto/Manual

Gain Control

Auto/Manual

Noise Reduction

3D

Privacy Masking

Up to 4 areas

Lens

Focal Length

1.18mm

Max Aperture

F2.0

Focus Control

Manual

Angle of View

H:180°

Lens Type

Fixed lens

Mount Type

Board-in Type

Video

Compression

H.264/ MJPEG

Resolution

960)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×2

40)

Frame Rate

Main Stream

4M(1~15fps)/3M(1 ~ 25/30fps)

Sub Stream

D1/CIF(1 ~ 30fps)

Bit Rate

H.264: 20K ~ 8192Kbps

Audio

Compression

G.711a/G.711u/PCM

Interface

1/1 channel In/Out(Built in Mic)

Network

Ethernet

RJ-45 (10/100Base-T)

Wi-Fi

N/A

Protocol

IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour

ONVIF

ONVIF,PSIA,CGI

Max. User Access

20 users

Smart Phone

iPhone, iPad, Android, Windows Phone

Auxiliary Interface

Memory Slot

Micro SD, Max 64GB

RS485

N/A

Alarm

1/1 channel In/Out

PIR Sensor Range

N/A

General

Power Supply

DC12V, PoE

Power Consumption

Max 6W

Working Environment

-30°C~+60°C, Less than 95% RH

Ingress Protection

N/A

Vandal Resistance

IK10

Dimensions

Φ110mm×54mm

Weight

0.25kg
