Model

HNC71120E-IR-Z

Camera

Image Sensor

1/1.7” 12Megapixel CMOS

Effective Pixels

4000(H)x3000(V)

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3(4)~1/100000s

Min. Illumination

0.05Lux/F1.4(Color); 0Lux/F1.4(IR on)

S/N Ratio

More than 50dB

Video Output

1 channel BNC（1.0Vp-p,75Ω）

Camera Features

Max. IR LEDs Length

50m

Day/Night

Auto(ICR)/Color/B/W

Backlight Compensation

BLC / HLC / DWDR

White Balance

Auto/Sunny/Night/Outdoor/Customized

Gain Control

Auto/Manual

Noise Reduction

3D

Privacy Masking

Up to 4 areas

EIS

Support

Ultra Defog

Support

Smart focus

Auto focus

Lens

Focal Length

4.1-16.4mm

Max Aperture

F1.53

Focus Control

Manual

Angle of View

H: 84.5 Ëš~ 34 Ëš

Lens Type

Zoom lens/Auto Iris

Video

Compression

H.264/H.264B/H.264H/ MJPEG

Resolution

12M(4000×3000)/8M(4096×2160)/8M(3840×2160)/1080P(1920×1

080)/720P(1280×720) /D1(704×576) /CIF(352×288)

Frame Rate

Main Stream

12M(1~15fps)/8M(4096×2160) (1~25/30fps)

Sub Stream

D1/CIF(1 ~ 25/30fps)

Third Stream

1080P/720P/D1(1 ~ 25/30fps)

Bit Rate

H.264: 32Kbps~ 16Mbps

ROI

Up to 4 areas

Audio

Compression

G.711a / G.711u/AAC

Interface

1/1 channel In/Out

Smart Function

Smart detection

Tripwire

Intrusion

Scene change

Missing/Abandoned

Audio detect

Defocus detect

Face detect

Network

Ethernet

RJ-45 (10/100/1000Base-T)

Wi-Fi

N/A

Protocol

IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour,802.1x

Compatibility

ONVIF, PSIA, CGI

Max. User Access

20 users

Smart Phone

iPhone, iPad, Android, Windows Phone

Auxiliary Interface

Memory Slot

Micro SD, Max 128GB

RS485

N/A

Alarm

2/1 channel In/Out

General

Power Supply

DC12V(AC24V optional), PoE (802.3at)

Power Consumption

Max24W (IR on)

Working Environment

-30°C~+60°C, Less than 95% RH

Ingress Protection

IP67

Dimensions

272.9mm×94.3mm×94.3mm

Weight

0.8Kg
