Model

NVR301C-04W

System

Main Processor

Dual-core embedded processor

Operating System

Embedded LINUX

Video& Audio

IP Camera Input

4 channel

Two-way Talk

1channel Input, 1channel Output, RCA

Display

Interface

1 HDMI,1 VGA

Resolution

1920×1080, 1280×1024, 1280×720, 1024×768

Display Split

1/4

OSD

Camera title, Time, Video loss, Camera lock , Motion detection, Recording

Recording

Compression

H.264/MJPEG

Resolution

5Mp(2560×1920)/3Mp(2048×1536)/1080P(1920×1080)/720P(1280×720)/D1 (704×576/704×480)

Record Rate

80Mbps

Bit Rate

48~ 8192kbps

Record Mode

Manual, Schedule(Regular(Continuous), MD, Alarm), Stop

Record Inter val

1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

Video Detection

Trigger Events

Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips

Video Detection

Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank

Playback & Backup

Sync Playback

1/4

Search Mode

Time/Date, Alarm, MD & Exact search (accurate to second), Smart search

Playback Function

Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera,  Previous  camera,  Full  screen,  Repeat,  Shuffle,  Backup  selection, Digital zoom

Backup Mode

USB Device/Network/Internal SATA burner

Network

Ethernet

1 RJ-45 port (10/100Mbps)

Wireless Network

Built-in WiFi module

Network Function

HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Ser ver, IP Search(Support Dahua IP camera, DVR, NVS and etc.)

Max. User Access

128 users

Smart Phone

iPhone, iPad, Android, Windows Phone

Storage

Internal HDD

1 SATA port, up to 4TB

Auxiliar y Interface

USB

2 ports (2 Rear),USB2.0

General

Power Supply

DC12V/2A

Power

Consumption

10W(without HDD)

Working

Environment

-10°C~+55°C / 10%~90%RH / 86~106kpa

Dimension

(W×D×H)

Smart 1U, 205mm×205mm×45mm

Weight

0.5KG(without HDD)
