> Item #1865

SavvyTech NVR301H-04/P 4CH MINI 1U NVR with 4POE, 80Mbps

Images are for illustration purpose and may not show the actual product.

Click to Enlarge

Model: NVR301H-04/P
Item #: 1865
Manufacturer: SavvyTech

MSRP: ~~$260.00~~
Our Price:

$184.80

(You save: $75.20)

Up to 4/8/16 channel IP camera input

Max 80Mbps incoming bandwidth

Up to SMp resolution preview&playback

H.264/MJPEG dual codec decoding

HDMI/VGA simultaneous video output

All channel synchronous realtime playback, GRID interface

Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek and etc.

ONVIF Version 2.4 conformance

3D intelligent positioning with Dahua PTZ camera

Support 1SATA HDD up to 4TB, 2 USB2.0

Support IPC UPnP, 4PoE ports

Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS

Model DH-NVR4104H-P I DH-NVR4108H-P I DH-NVR4116H-P
System
Main Processor Dual-core embedded processor
Operating System Embedded LINUX
Video& Audio
IP Camera Input	4 channel I 8 channel 116 channel
Two-way Talk	!channel Input, !channel Output, RCA
Display
Interface	1HDMI,l VGA
Resolution	1920×1080, 1280×1024, 1280×720, 1024×768
Display Split	l/4 ll/4/8/9 1114/8/9/16
OSD	Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Compression	H.264/MJPEG
Resolution	5Mp(2560 x 1920)/3Mp(2048 x 1536)/1080P(1920 x 1080)/720P(1280x 720)/Dl (704x 576/704 x 480)
Record Rate	80Mbps
Bit Rate	488192kbps
Record Mode	Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval	1 120 min (default: 60 min), Pre-record: 1 30 sec, Post-record: 10 300 sec
Video Detection
Trigger Events	Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips
Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Playback & Backup
Sync Playback	l/4 ll/4/9 ll/4/9/16
Search Mode	Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
Playback Function	Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode	USB Device/Network/Internal SATA burner
Network
Ethernet	1RJ-45 port (10/lOOMbps)
PoE	4 ports (IEEE802.3at)
Network Function	HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.)
Max. User Access	128 users
Smart Phone	iPhone, iPad, Android, Windows Phone
Storage
Internal HDD	1SATA port, up to 4TB
Auxiliary Interface

USB	2 ports,USB2.0
General
Power Supply	Single, DC48VI1.5A
Power Consumption	NVR: lOW(without HDD)
Power Consumption	PoE: Max 25.5W for single port
Working Environment	-10°C +55°C I 10% 90%RH I 86 106kpa
Dimension (WxDxH)	Mini lU, 325mmx240mmx45mm
Weight	1.25KG(without HDD)
