| Compression Format | H.264 |
| OS | Embedded Linux |
| Video/Audio Output | |
| IP Video Input | 16-ch, Max 40Mbps Input |
| VGA Output | 1-ch, resolution: 1920×1080P/60Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
| CVBS Output | 1-ch, BNC (1.0 Vp-p, 75 Ω) |
| HDMI Output | 1-ch, resolution: 1920 × 1080P /60Hz, 1920 × 1080P /50Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720/60Hz, 1024 × 768 /60Hz |
| Recording Resolution | 5MP / 3MP / 2MP / 1080P / 720P / VGA / D1 / VGA / DCIF / 2CIF / CIF / QCIF |
| Simultaneous Playback | 8-ch, 4CIF (Real-time) 8-ch, 4-ch 720P, 2-ch 1080P, 5 MP (No Realtime) |
| Playback Resolution | 5MP / 3MP / 2MP / 1080P / 720P / VGA / D1 / VGA / DCIF / 2CIF / CIF / QCIF |
| Dual Stream | Main and Sub-Streams |
| Audio Input | 1-ch BNC |
| Audio Output | 1-ch BNC |
| Backup Format | MP4 |
Storage |
|
| SATA | 2 SATA Interfaces for 2HDDs |
| e-SATA | No |
| Capacity | Up to 4TB capacity for each disk |
External Interface |
|
| Network Interface | 1 RJ45 10M/100M/1000M adaptive Ethernet |
| USB Interface | 2 USB 2.0 Interfaces |
| Serial Interface | 1 RS-485 Interface, 1xRS-232 |
| Alarm Input: | 4 |
| Alarm Output: | 2 |
General |
|
| Mobile App | NVMS7000 for iPhone/iPad/Android |
| Power Supply | 100 ~240VAC |
| Consumption | ≤ 15 W (without hard disk) |
| Working Temperature | -10 °C ~ 55 °C |
| Humidity | 10%~90% |
| Chassis | 19-ich rack-mounted 1U chassis |
| Dimensions | 445 × 290 ×45 mm (W x D x H) |
| Weight | ≤ 2 Kg ( without hard disk) |
