| Image Sensor | 1/3” sensor |
| Min. Illumination | 0.1 lux@F1.4, AGC on 0 lux with IR |
| Shutter Speed | 1/25s ~ 1/100,000s |
| Lens | 2.8 ~ 12 mm @F1.2, angle of view: 98° ~ 30.2° |
| Lens Mount | Φ14 |
| Day & Night | ICR |
| Digital Noise Reduction | 3D DNR |
| Wide Dynamic Range | Digital WDR |
| Backlight compensation | Yes,zone configurable |
| Compression Standard | |
| Video Compression | H.264 / MJPEG |
| H.264 compression profile | Main profile |
| Bit Rate | 32 Kbps ~ 16 Mbps |
| Audio Compression | G.711/G.726 |
| Audio Bit Rate | 64Kbps(G.711)/16Kbps(G.726) |
| Image | |
| Max. Resolution | 2048 × 1536 |
| Frame Rate | 60Hz: 20fps (2048 x 1536), 30fps (1920 × 1080), 30fps (1280 x 720) 50Hz: 20fps (2048 x 1536), 25fps (1920 × 1080), 25fps (1280 x 720) |
| Image Settings | Saturation, brightness, contrast adjustable through client software or web browser |
| Network | |
| Network Storage | NAS ( iSCSI optional) |
| Alarm Trigger | Motion detection.tampering alarm |
| Protocols | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos (SIP, SRTP, IPv6 optional) |
| System Compatibility | ONVIF, PSIA, CGI |
| General functionalities | Dual stream, user authentication, watermark |
| Interface | |
| Communication Interface | 1 RJ45 10M / 100M ethernet port |
| On-board Storage | Built-in Micro SD card slot, up to 32 GB |
| General | |
| Working Temperature /Humidity |
-30 °C ~ 60 °C (-22 °F ~ 140 °F), humidity 95% or less (non-condensing) |
| Power Supply | DC12V ± 10%, PoE (802.3af) |
| Power Consumption | Max. 5.5W(7.5W with ICR on) |
| Ingress protection level | IP66 |
| IR Range | Up to 90ft(About 30 meters) |
| Dimension | Φ105×295.6mm(Φ4.13"×11.64") |
| Weight | 1200g(2.65 lb) |
