| Video | Camera Input | 8 BNC |
| Individual HD/Analog | All Hybrid | |
| Available Source | TVI 720p25,30/1080p25,30/Composite/960H/Mixed | |
| Output | 1 HDMI (Main Display or Programmable HD Spot) 1 VGA (Main Display or Programmable HD Spot) 1 Composite (Programmable SPOT) |
|
| IP Camera | Spec: ONVIF 2.3, RTSP, H.264, Dual Stream Num: 4 Restriction: Cannot display HD SPOT, SPOT |
|
| Audio | Audio Input | 4 RCA |
| Output | 1 RCA | |
| Sensor In | 4 (NC, NO selectable) | |
| Alarm out | 1 Relay | |
| Operating System | Embedded Linux OS | |
| Display | Speed | Real Time |
| Resolution (Pixel) | 1280×1024, 1280×720, 1920×1080 | |
| Screen Split | 1 / 4 / 6 / 8 / 9 | |
| Recording | CODEC | H.264 / JPEG for 3G, Dual CODEC |
| Resolution (Pixel) | 1080p, 720p, 960x540 (1080p25,30) 720p, 960x540 (720p25,30) 960H, 720H (Composite, 960H) |
|
| Picture Quality | 4 Steps (Super, High, Medium, Low) | |
| Speed | NTSC : 240fps@720p / 240fps@1080p PAL : 200fps@720p / 200fps@1080p |
|
| Playback | Display | 1 / 4 / 6 / 8 / 9 |
| Search Mode | Calendar, Event ,POS , Panorama, Thumbnail | |
| Speed | NTSC : 120fps@1080p PAL : 200fps@1080p |
|
| Fast/Slow speed | Normal, REW & FF [recorded speed ×2, ×4, ×8,×16,×32,×64,×1/2,×1/4], Frame to frame, Pause | |
| Network | Network Interface | Gigabit Ethernet x 2 |
| Speed | 90fps@1080p 70fps@1080p | |
| Protocol | TCP/IP, HTTP, DHCP | |
| Application | Windows 7 / 8 (PC Client system & IE)/MAC | |
| Web Browser | Internet Explorer, Safari, FireFox, Chrome | |
| Smart phone App | MR. Patrol : Android, iPhone for Live & Search | |
| Backup | Interface | USB 2.0 × 2 |
| Backup device | External HDD, CD & DVD-RW, Network, Thumb Drive | |
| The Number of HDD | 2 SATA | |
| Others | Power Consumption | 60W |
| Operating Temperature | 5 ~40°C(41~104°F) | |
| Relative Humidity | Maximum 80% non-condensing | |
| Dimension | 13.39(W)×9.84(D)×2.36(H)inches / 340(W)×250(D)×60(H)mm | |
