| SYSTEM | ||||
| Compression | Standard H.264 High Profile | |||
| CPU | Cortex A9 | |||
| OS | Embedded Linux | |||
| VIDEO | ||||
| Input | BNC x 32 Support 1080P@25 / 30fps, 720P@25 / 30 / 50 / 60fps, 960H, D1 input |
|||
| IP Input/Access Bandwidth | NO | |||
| Ouput | HDMI x 1: 1920 x 1080 VGA x 1: 1920 x 1080 |
|||
| AUDIO | ||||
| Input | RCA x 16 | |||
| Output | RCA x 1 | |||
| 2-way audio | RCA x 1 | |||
| RECORD | ||||
| Resolution | 1080P: 1920 x 1080, 720P : 1280 x 720, WD1, D1 | |||
| Frame Rate | 720P: 800 fps ( PAL ) 960 fps ( NTSC ) 1080P: 400 fps ( PAL ) 480 fps ( NTSC ) |
|||
| Bit Rate | 1 M ~ 4 Mbps | |||
| Encode | VBR / CBR | |||
| Quality | 6 Level | |||
| Mode | Manual, Timer, Motion, Sensor | |||
| File Manager | Lock, unlock, reserving time | |||
| IP Input | ||||
| Resolution | NO | |||
| PLAYBACK | ||||
| Playback | 8 CH | |||
| Search | Time/calendar search, event (motion,external alarm) | |||
| Smart Search | Highlighted date and time to display the channel record | |||
| Function | Play, Pause, FF, FB, Digital zoom | |||
| ALARM | ||||
| Mode | Sensor, Motion, Video Loss | |||
| Input | 16 CH | |||
| Output | 4 CH | |||
| Triggering | Record, PTZ move, alarm out, e-mail, etc | |||
| NETWORK | ||||
| Interface | RJ45 10M/100M/1000M adaptive ethernet network port x 1 | |||
| Protocol | TCP / IP, UDP, DHCP, DNS, PPPOE, DDNS | |||
| Others | 10 users online, dual stream | |||
| CELLPHONE | ||||
| OS | iPhone, Andriod | |||
| Function | Multi-screen surveillance ( for certain model ) , record, snapshot, PTZ control, save the device list | |||
| I/O | ||||
| HDD | SATA x 8 | |||
| RS485 | RS485 x 2, one for PTZ, another for keyboa rd | |||
| USB | USB 2.0 x 2, one for mouse, another for USB backup device | |||
| IR Controller | Yes | |||
| OTHERS | ||||
| Power Supply | ATX | |||
| Consumption | < 40W ( without HDD ) | |||
| Dimensions | 430 mm x 450 mm x 89 mm (W x D x H) | |||
| Work Environment | -10 ~ 50 °C =, 10% ~ 90% Humidity | |||
