| Camera | |
| Image Sensor | 2 MP CMOS Image Sensor |
| Signal System | PAL / NTSC |
| Effective Pixels | 1930(H)×1088(V) |
| Min. Illumination | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR |
| Lens | 2.8mm |
| Angle of View | 105.8° |
| Lens Mount | M12 |
| Angle Adjustment | Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360° |
| Day & Night | ICR |
| Synchronization | Internal synchronization |
| Video Frame Rate | 1080p@25fps/1080p@30fps |
| HD Video Output | 1 Analog HD output |
| S / N Ratio | More than 52dB |
| Menu | |
| AGC | Support |
| D/N Mode | Color/ BW/ EXT |
| White Balance | Auto/ Manual |
| BLC | Support |
| Language | English/Chinese |
| Function | Digital noise reduction, Mirror |
| General | |
| Working Temperature / Humidity | -40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply | 12 VDC |
| Power Consumption | Max. 2.5W |
| Weather Proof Ratings | IP66 |
| IR Range | Up to 20m |
| Communication | Up the coax |
| Dimensions | Φ 110 × 93.2 mm(Φ 4.33in × 3.67in) |
| Weight | 260g (0.57 lb) |
