• 1/2.9” Sony CMOS
• 4.0mm Fixed Lens
• 25 IR LEDs
• True Day & Night(ICR)
• DNR (Digital Noise Reduction)
• AWB (Auto White Balance)
• SENS-UP
• EX-SDI / HD-SDI selectable
| Resolution | EX/HD-SDI(1080p, 720p) / 1000 TV line over |
| Sensor | 1/2.9" Sony CMOS |
| Total Pixels | 2000(H) × 1241(V) = 2.5M Pixel |
| Effective Pixels | 1944(H) × 1092(V) = 2.1M Pixel |
| Scanning System | Progressive |
| S/N (Y signal) | More than 52 dB (AGC Off) |
| Video Output | SMPTE292M (HD-SDI) |
| Min.Illumination | 0 lux at IR On |
| White Balance | Auto |
| Electronic Shutter Speed | Auto (1/30sec ~ 1/60,000sec) |
| Brightness | Adjustable (0 ~ 20 Step) |
| DNR | HIGH |
| Day & Night | EXTERN |
| Language | ENGLISH |
| Operating Temperature / Humidity | -10°C~+50°C / 30%~80% RH |
| Storage Temperature / Humidity | -20°C~+60°C / 20%~90% RH |
| Power | DC 12V Only |
| Signal Transmission | The distant difference is occurred according to cable option and other circumstances. (based on RG59: 100M) |
