| SYSTEM | |
| Compression | Standard H.264 / MPEG4 |
| CPU | Cortex A9 |
| OS | Embedded Linux |
| VIDEO | |
| Output | VGA x 1 : 1920 x 1080 HDMI x 1 : 1920 x 1080 |
| Resolution | 3MP / 1080P / 960P / 720P |
| Frame Rate | 32 CH 3MP / 1080P / 960P / 720P @30 fps |
| AUDIO | |
| Input | 8 CH IPC input |
| Output | RCA x 1 |
| 2-way audio | RCA x 1 |
| RECORD | |
| Resolution | 3MP : 2048 x 1536 1080P : 1920 x 1080 960P : 1280 x 960 720P : 1280 x 720 D1 : 704 x 576 |
| Frame Rate | 800 fps ( PAL ) 960 fps ( NTSC ) |
| Bit Rate | 256Kbps ~ 12Mbps |
| Encode | CBR |
| Quality | 6 Level |
| Mode | Manual, Timer, Motion, Sensor |
| File Manager | Lock, Unlock, Reserving Time |
| PLAYBACK | |
| Playback | 4 CH |
| Search | Time/calendar search, event(motion) |
| Smart Search | Highlighted date and time to display the channel record |
| Function | Play, Pause, FF, FB, Digital zoom |
| ALARM | |
| Mode | Sensor, Motion, Video Loss |
| Input | 4 CH local input, support IPC alarm input |
| Output | 1 CH |
| Triggering | Record, PTZ move, alarm out, e-mail, etc |
| NETWORK | |
| Interface | RJ45 10M/100M/1000M adaptive ethernet network port x 1 |
| Protocal | TCP / IP, UDP, DHCP, DNS, PPPOE, DDNS |
| Others | 20 users online, dual stream |
| CELLPHONE | |
| OS | iPhone, Andriod |
| Function | Multi-screen surveillance, record, snapshot, PTZ control, save the device list |
| PORT | |
| HDD | SATA x 2 |
| RS485 | RS485 x 1, connect to PTZ or keyboard |
| USB | USB 3.0 x 1, USB 2.0 x 1, one for mouse, another for USB backup device |
| Remote Controller | Yes |
| OTHERS | |
| Power Supply | DC 12V |
| Consumption | < 10W (without HDD) |
| Dimensions | 400 mm x 300 mm x 55 mm (W x D x H) |
| Work Environment | -10 ~ 55 °C =, 10% ~ 90% Humidity |
