| SYSTEM |
| Compression |
Standard H.264 / MPEG4 |
| CPU |
Cortex A9 |
| OS |
Embedded Linux |
| VIDEO |
| Output |
VGA x 1:1080P HDMI x 1:1080P |
| IP INPUT |
| Resolution |
3MP / 1080P / 960P / 720P |
| Frame Rate |
32 CH 3MP / 1080P / 960P / 720P @30 fps |
| AUDIO |
| Input |
32 CH IPC input |
| Output |
RCA x 1 |
| 2-way audio |
RCA x 1 |
| RECORD |
| Resolution |
3MP : 2048 x 1536, 1080P : 1920 x 1080 960P : 1280 x 960, 720P : 1280 x 720 D1 : 704 x 576 |
| Frame Rate |
800 fps ( PAL ) 960 fps ( NTSC ) |
| Bit Rate |
256Kbps ~ 12Mbps |
| Encode |
VBR / CBR |
| Quality |
6 Level |
| Mode |
Manual, Timer, Motion, Sensor |
| File Manager |
Lock, unlock, reserving time |
| PLAYBACK |
| Playback |
16 CH |
| Search |
Time/calendar search, event (motion,external alarm) |
| Smart Search |
Apply different colors to display whether a channel in a period of time recording or not |
| Function |
Play, Pause, FF, FB, Digital zoom |
| ALARM |
| Mode |
Sensor, Motion, Video Loss |
| Input |
16 CH local input, support IPC alarm input |
| Output |
4 CH |
| Triggering |
Record, alarm out, e-mail, etc |
| NETWORK |
| Common Interface |
GMAC x 1 |
| PoE Interface |
RJ45 x 16 |
| Protocal |
TCP / IP, UDP, DHCP, DNS, PPPOE, DDNS,E-mail |
| Others |
18 users online, dual stream |
| CELLPHONE |
| OS |
iPhone, Andriod |
| Function |
Multi-screen surveillance, record, snapshot, PTZ control, save the device list |
| PORT |
| HDD |
SATA x 8 |
| RS485 |
RS 485 x 1, support PTZ and keyboard |
| USB |
USB 3.0 x 1, USB 2.0 x 1, one for mouse, another for USB backup device |
| Remote Controller |
Yes |
| OTHERS |
| Power Supply |
ATX |
| Dimensions |
430 mm x 450 mm x 89 mm (W x D x H) |
| Work Environment |
-10 ~ 55 °C =, 10% ~ 90% Humidity |
