* SOLD OUT * IP Power NIT-C222F-W 2 MP IP IR Dome Camera w/ 24 IR LEDs & 3.6mm Fixed Lens
Images are for illustration purpose and may not show the actual product.
Model:
NIT-C222F-W
Item #: 1525
MSRP:
$120.00
Our Price:
$104.00
(You save: $16.00)
- 1080p (1920 x 1080) Full Real Time Coding
- Maximum Resolution: 1920 x 1080
- ICR Auto Switch, True Day & Night
- 10 ~ 20m IR Night View Distance
- 3D DNR, Digital WDR
- Support Corridor Pattern
- ROI Coding
- PoE (Power over Ethernet) Power Supply
- Support Smart Phone, iPad, Remote Monitoring
- Support P2P / Triple Streams
- 3.6mm Fixed Lens
- H.264 / 24 IR LED
- Water Proof (IP66)
- DC 12V / White Casing
| CAMERA |
| Image Sensor |
1 / 3 “CMOS |
| Image Size |
1920×1080 |
| Electronic Shutter |
1 / 25 s ~ 1 / 100000 s |
| Min. Illumination |
0 Lux ( IR LED ON ) |
| Lens |
3.6 mm Fixed Lens |
| Lens Mount |
M12 |
| IMAGE |
| Video Compression |
H.264 / MJPEG |
| Resolution |
1080P ( 1920 x 1080 ), 720P ( 1280 x 720 ), D1, CIF, 480 x 240 |
| Multi-Stream |
1920 x 1080 ( 1 ~ 30fps ) / 1280 x 720 ( 1 ~ 30fps ) / 1280 x 720 ( 1 ~ 10fps) / D1 ( 1 ~ 30fps ) / CIF ( 1 ~ 30fps ) CIF ( 1 ~ 30fps ) / 480 x 240 ( 1 ~ 30fps ) |
| Bit Rate |
64 Kbps ~ 8 Mbps |
| Encode Mode |
VBR / CBR |
| Quality |
Five levels under VBR; Freely adjustable under CBR |
| Image Settings |
Corridor pattern, Saturation, Brightness, Chroma, Contrast, Wide Dynamic, Sharpen, NR,etc. adjustable through client software or web browser |
| FUNCTIONS |
| Remote Monitoring |
IE browsing,CMS remote control |
| Online Connection |
Support simultaneous monitoring for up to 4 users; Support multi-stream real time transmission |
| Protocol |
TCP / IP, UDP, DHCP, NTP, RTSP, PPPoE, DDNS, Protocol SMTP, FTP |
| Storage |
Network remote storage |
| Smart Alarm |
Motion Alarm |
| Day & Night |
ICR |
| PoE |
Yes |
| IR Distance |
10 ~ 20m |
| Water-proof |
IP66 |
| INTERFACE |
| Network |
RJ45 |
| Audio |
No |
| OTHERS |
| Power Supply |
DC 12V / PoE |
| Power Consumption |
< 2.5W |
| IR Consumption ON |
< 4.5W |
| Operating Environment |
-40°C ~ 50°C, 10% ~ 90% humidity |
| Dimensions |
ø116mm × 91mm (ø4.6 x 3.6 in) |
