Video | |
Camera input | 16 POE |
Technology | ONVIF 2.3, RTSP, dual stream |
# of IP Camera | 16 |
Output | 1 HDMI (Main Display) 1 VGA (Main Display) |
Other I/O | |
Audio input | 1 RCA |
Audio Output | 1 RCA |
Sensor In | 16 (NC, NO selectable) |
Alarm out | 1 relay |
Operating System | Embedded Linux OS |
Display | |
Speed | Real Time |
Resolution (Pixel) | 1280×1024, 1280×720, 1920×1080, 3840×2160(HDMI only) |
Split screen | 1,4,6,8,9,13,16 |
Main IPC | |
Resolution (Pixel) / fps | main: upto 8MP@ 30 dual: upto 960×540 |
Total Bitrate | 120Mbps |
Channel Bitrate | 7.5 Mbps |
Playback | |
Display | 1,4,6,8,9,13,16 |
Search mode | Calendar, Event ,POS , Panorama, Thumbnail |
Fast/Slow speed | Normal, REW & FF [recorded speed ×2, ×4, ×8,×16,×32,×64,×1/2,×1/4], Frame to frame, Pause |
Other | |
Backup device | External HDD, CD&DVD-RW, Network, Thumb Drive |
Network Interface | Gigabit Ethernet |
The number of HDD | 2 SATA + 1 eSATA (upto 12 bays, No capacity limit ; 6TB or more) |
Power Consumption | 190W (SMPS) |
Operating Temperature | 5 ~40ºC(41~104ºF) |
Relative Humidity | Maximum 80% non-condensing |
Dimension | 380(W)×340(D)×50(H) mm |
