| Camera | |
| Image Sensor | 1/3"Sensor |
| Signal System | NTSC / PAL(Euro Version) |
| Effective Pixels | 1280(H)×720(V) |
| Min. Illumination | 0.01 Lux @ (AGC ON),0 Lux with IR |
| Shutter Speed | NTSC: 1/30 s(PAL: 1/25 s) to 1/50,000 s |
|
Lens
|
2.8-12mm |
| Day & Night | ICR |
| Synchronization | Internal synchronization |
| Video Frame Rate | NTSC:720p@30fps/PAL:720p@25fps |
| HD Video Output | 1 Analog HD output |
| S/N Ratio | More than 52dB |
| General | |
| Working Temperature /Humidity |
-40°F - 140°F (-40 °C - 60 °C) |
| Humidity 90% or less (non-condensing) | |
| Power Supply | 12V DC |
| Power Consumption | Max. 5W |
| Weather Proof Ratings | IP66 |
| IR Range | Up to 131ft(40m) |
| Dimension | 4.1” x 3.4” x 11.9”(105.0× 86.9 × 302.3 mm) |
| Weight | 3.3lb(1500g) |
