Camera | |
Image Sensor | 1/2.7" CMOS |
Signal System | NTSC/PAL |
Effective Pixels | 1928(H)*1088(V) |
Min. Illumination | 0.01 Lux, 0 Lux with IR |
Shutter Speed | 1/30 (1/25)s to 1/50,000s |
Lens | 2.8mm, FOV: 103° |
Day & Night | ICR |
Synchronization | Internal |
Video Frame Rate | 1080p@30fps/ 1080p@25fps |
HD Video Output/span> | 1 HD-TVI Output |
S/N Ratio | More than 62dB |
Menu | |
AGC | Support |
D/N Mode | Color/BW/Smart |
White Balance | ATW/MWB |
BLC | Support |
Function | True WDR, DNR, Mirror, SMART IR |
General | |
Working Temperature/ Humidity | -40 °F - 140 °F (-40 °C - 60° C) Humidity 90% or less (non-condensing) |
Power Supply | DC 12V |
Power Consumption | Max. 5W |
Weather Proof Ratings | IP66 |
IR Range | Up to 65ft (20m) |
Dimension | 2.3” × 2.2” × 6.1" (58.5×55.5×153.6mm) |
Weight | 0.8lb (370g) |
