| Camera | |
| Image Sensor | 1/2.7" CMOS |
| Signal System | NTSC/PAL |
| Effective Pixels | 1930(H)*1088(V) |
| Min. Illumination | 0.01 Lux, 0 Lux with IR |
| Shutter Speed | 1/30(1/25) s to 1/50,000 s |
| Lens | Motorized Lens: 2.8-12mm Angle of View: 105.2°-32.8° |
| Day & Night | ICR |
| Synchronization | Internal |
| Video Frame Rate | 1080p@30fps/1080p@25fps |
| HD Video Output | 1 HD-TVI Output |
| S/N Ratio | More than 52dB |
| Menu | |
| Camera ID | On/off (0-255) |
| AGC | Support |
| D/N Mode | Color/BW/Smart |
| White Balance | Auto/ User/ Push/ 8000K/ 6000K/ 4200K/ 3200K/HOLD |
| Privacy Mask | On/ Off, maximum 2 zones |
| Motion Detection | On/ Off |
| BLC | Support |
| Anti-Flicker | On/off |
| Language | English/ Chinese |
| Function | Digital noise reduction, Mirror |
| General | |
| Working Temperature /Humidity |
-40 °F - 140 °F (-40°C - 60 °C) Humidity 90% or less (non-condensing) |
| Power Supply | DC 12V |
| Power Consumption | Max. 5W |
| Weather Proof Ratings | IP66 |
| IR Range | Up to 131ft(40m) |
| Dimension | 5.7”×4.9” (145.3×124.2mm) |
| Weight | 2.0lb(880g) |
