*Must be Used with HD-TVI 3.0 DVRs
CAMERA | |
Image Sensor | 1/3" CMOS |
Signal System | NTSC/PAL |
Effective Pixels | 2052(H)*1536(V) |
Min. Illumination | 0.01Lux, 0 Lux with IR |
Lens | 3.6mm |
Shutter Speed | 1/30 (1/25) to 1/50,000 s |
Day & Night | ICR |
Synchronization | Internal |
Video Frame Rate | 1920x1536@18fps |
HD Video Output | 1 HD-TVI Output |
S/N Ratio | More than 62dB |
MENU | |
AGC | Support |
D/N Mode | Color/ BW/ SMART |
White Balance | ATW/ MWB |
BLC | Support |
Function | DNR, Mirror, SMART IR |
GENERAL | |
Working Temperature /Humidity |
-40 °F ~ 140 °F (-40 °C ~ 60 °C) Humidity 90% or less (non-condensing) |
Power Supply | DC 12V, AC 24V |
Power Consumption | Max. 5W |
Weather Proof Ratings | IP66 |
IR Range | Up to 65ft (40m) |
Dimensions | 3.6" x 3.3" x 2.7" (91.0 x 82.6 x 68.3mm) |
Weight | 0.8 lbs (350g) |
