| Camera | |
| Image Sensor | 1/2.7" CMOS |
| Signal System | NTSC/PAL |
| Effective Pixels | 1928(H)*1088(V) |
| Min. Illumination | 0.01 Lux, 0 Lux with IR |
| Shutter Speed | 1/30 (1/25)s to 1/50,000s |
| Lens | 3.6mm, FOV: 82.2° |
| Day & Night | ICR |
| Synchronization | Internal |
| Video Frame Rate | 1080p@30fps/ 1080p@25fps |
| HD Video Output/span> | 1 Analog HD Output |
| S/N Ratio | More than 62dB |
| Menu | |
| AGC | Support |
| D/N Mode | Color/BW/Smart |
| White Balance | ATW/MWB |
| BLC | Support |
| Function | True WDR, DNR, Mirror, SMART IR |
| General | |
| Working Temperature/ Humidity | -40 °F - 140 °F (-40 °C - 60° C) Humidity 90% or less (non-condensing) |
| Power Supply | DC 12V |
| Power Consumption | Max 5W |
| Weather Proof Ratings | IP66 |
| IR Range | Up to 65t(20m) |
| Dimension | 3.6” × 3.3” × 2.7." (91.0×82.6×68.3mm) |
| Weight | 0.8lb (350g) |
