| VIDEO/ AUDIO INPUT | |
| Video Compression | H.264 |
| Video Input | 8CH BNC (1.0 Vp-p, 75 Ω ), PAL / NTSC self-adaptive |
| Audio Compression | G.711u |
| Audio Input | 1-ch, RCA (2.0 Vp-p, 1 kΩ ) |
| Two-way Audio Input | 1-ch, RCA (2.0 Vp-p, 1 kΩ ) |
| VIDEO/ AUDIO OUTPUT | |
| HDMI/VGA Output | 1920 × 1080 |
| Frame Rate | 1080P: 100fps(PAL)/120fps(NTSC) 720P/WD1/D1: : 200(PAL)/240(NTSC) |
| Video Bit Rate | 1MKbps-6Mbps |
| Audio Output | 1-ch, RCA (Linear, 1 kΩ) |
| Audio Bit Rate | 64 Kbps |
| Dual-Stream | Support |
| Stream Type | Video, Video & Audio |
| Synchronous Playback | 8CH |
| Playback Resolution | 1080P / 720P |
| NETWORK | |
| Remote Connections | 128 |
| Network Protoco | TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP™, HTTPS |
| HARD DISK | |
| SATA | 2 SATA |
| Capacity | Up to 4TB capacity for each disk |
| EXTERNAL INTERFACE | |
| Network Interface | 1:10M / 100M/1000M self-adaptive Ethernet interface |
| Serial Interface | RS-485, Keyboard |
| USB Port | 2 × USB2.0 |
| Alarm In/Out | - |
| GENERAL | |
| Power Supply | DC 12V |
| Consumption | ≤ 14W |
| Working Temperature | -10 ° C ~ + 50 ° C(14° F - 122° F) |
| Working Humidity | 10% ~ 90% |
| Casing | 1U Casing |
| Dimensions | 430 × 300 × 55 mm (16.9 × 11.8 × 2.2 inch) |
| Weight | ≤ 3Kg (6.6lb) |
