| Camera | |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Effective Pixel | 1280(H) × 720(V) |
| Min. Illumination | Color: 0.05Lux @ (F1.6, AGC On), B/W: 0.01Lux @ (F1.6, AGC On) |
| White Balance | Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
| AGC | Auto / Manual |
| S / N Ratio | ≥ 52dB |
| Digital Noise Reduction | 3D DNR |
| Backlight compensation | BLC |
| Wide Dynamic Range | Digital WDR |
| Defog | Support |
| Shutter Speed | 1/1~ 1/10,000s |
| Day and Night | IR Cut Filter |
| Digital Zoom | 16X |
| Focus Mode | Auto / Semiautomatic / Manual |
| Privacy Mask | 2 privacy masks programmable |
| Lens | |
| Focal Length | 4.7-94mm, 20x |
| Zoom Speed | Approx.3s (Optical Wide-Tele) |
| Angle of View | 58.3 ~ 3.2 degree (Wide-Tele) |
| Min. Working Distance | 10 ~1000mm (Wide-Tele) |
| Aperture Range | F1.6 ~ F3.5 |
| Pan and Tilt | |
| Pan / Tilt Range | Pan: 360° endless; Tilt: -2° ~ 90°(Auto Flip) |
| Pan / Tilt Speed | Pan manual speed: 0.1° ~ 160°/s, Pan preset speed: 160°/s Tilt manual speed: 0.1° ~ 120°/s, Tilt preset speed: 120°/s |
| Proportional Zoom | Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset | 256 |
| Patrol | 8 patrols, up to 32 presets per patrol |
| Park Action | Pattern/Pan scan/Tilt scan/Frame scan/Panorama scan/Random scan |
| Power-Off Memory | Support |
| PTZ Position Display | On / off |
| Preset Freezing | Support |
| Local Video and Audio | |
| Alarm Input / Output | 1 input 0-5v DC / 1 replay output, alarm response actions configurable |
| Audio Input / Output | 1 mic/Line in, 2-2.4V[p-p]; output impedance: 1KΩ, ±10% / 1 output, Line level, impedance: 600Ω |
| Network | |
| Ethernet | 10Base-T / 100Base-TX, RJ45 connector |
| Max. Image Resolution | 1280×720 |
| Frame Rate | 60Hz: 30 fps (1280×720);50Hz: 25 fps (1280×720) |
| Image Compression | H.264/MJPEG |
| SVC | Support |
| ROI Encoding | Support 2 areas with adjustable levels |
| Audio Compression | G.711u /G.711a /G.726 /MP2L2 |
| Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP,TCP, UDP,IGMP, ICMP, DHCP, PPPoE |
| Simultaneous Live View | Up to 6 |
| Streams | Dual streams |
| SD Memory Card | Built-in micro SD card slot, up to 64GB, support edge recording |
| Integration | |
| Application Programming | Open-ended API, support Onvif, PSIA and CGI |
| Web Browser | IE 7+, Chrome 18+, Firefox 5.0+, Safari 5.02+ |
| General | |
| Power | 24VAC/PoE+(802.3at), Max18W; -C: 24VAC/PoE(802.3af), Max 12W |
| Working Temperature | -22°F ~ 149°F (-30°C ~ 65°C) ; -C: 14°F ~122°F (-10°C ~ 50°C) |
| Humidity | 90% or less |
| Protection Level | IP66 standard(PTZIP211X20) TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Dimensions | Φ7.06”×9.43”(Φ179.4×239.5mm )(PTZIP211X20) Φ6.50”×6.61”(Φ165×168mm) (PTZIP211X20-C) |
| Weight | Approx. 4.41Ibs (2Kg) |
