| Camera | |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Min. Illumination | Color: 0.1 Lux @ (F1.2, AGC ON); B/W: 0.01 Lux @ (F1.2, AGC ON) |
| Shutter Speed | 1 s to 1/100,000 s |
| Slow Shutter | Support |
| Lens Mount | C/CS Mount |
| Auto Iris | DC Drive |
| Day & Night | IR cut filter with auto switch |
| DNR | 3D DNR |
| Wide Dynamic Range | 120dB |
| Compression Standard | |
| Video Compression | H.264 Zip+/H.264/MPEG4/MJPEG |
| H.264 Type | Baseline Proï¬le / Main Proï¬le / High Proï¬le |
| Video Bit Rate | 32 Kbps ~ 16 Mbps |
| Audio Compression | G.711/G.722.1/G.726/MP2L2 |
| Audio Bit Rate | 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
| Image | |
| Max Resolution | 2048x1536 |
| Frame Rate | 60Hz: 20fps (2048 × 1536), 30fps (1920 × 1080), 30fps (1280 × 720) 50Hz: 20fps (2048 × 1536), 25fps (1920 × 1080), 25fps (1280 × 720) |
| Third Stream | Independent with Main Stream and Sub Stream, up to 50Hz: 20fps (2048 × 1536) 60Hz: 20fps (2048 × 1536) |
| BLC | Support |
| Smart Defog | Support |
| EIS | Support |
| Image Setting | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| Day/Night Switch | Auto/Schedule/Triggered by Alarm In |
| ROI | Support 4 different areas conï¬guration in all the three streams with adjustable 6 levels. Automatically dynamic tracking with face detection can be conï¬gured. |
| Picture Overlay | LOGO picture can be overlaid on video with 128x128 24bit bmp format |
| Network | |
| Network Storage | NAS (Support NFS,SMB/CIFS) |
| Alarm Trigger | Intrusion detection, Defocus detection, Motion detection, Face detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
| Protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Security | User Authentication, Watermark, IP address ï¬ltering, Anonymous access |
| Standard | ONVIF, PSIA, CGI, ISAPI |
| Interface | |
| Audio Input | 1- ch 3.5 mm audio interface, Mic in/Line in. 1 built-in Microphone |
| Audio Output | 1-ch 3.5 mm audio interface |
| Communication Interface | 1 RJ45 10M/100M Ethernet port, 1 RS-485 interface and 1 RS-232 interface |
| Alarm Input | 1 |
| Alarm Output | 1 |
| Video Output | 1Vp-p composite output (75 Ω/BNC) |
| On-board Storage | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Button | Yes |
| General | |
| Working Temperature | -22 ° F ~ 140 °F (-30 °C ~ 60 °C) Humidity 95% or less (non-condensing) |
| Power Supply | 24 V AC ± 10%, 12 V DC ± 10%, PoE (802.3af) |
| Power Consumption | Max. 6.5 W (Max. 9.5 W with IR cut ï¬lter on) |
| Dimensions | 2.68” × 2.56” × 5.70”(69.8×58×145 mm) |
| Weight | 1.83lbs (830g) |
